51
AVR
Appendix
Surround Mode Description Incoming Bitstream or Signal
Dolby Pro Logic IIx
Music This mode is similar to Dolby Pro Logic II Movie, with an added surround back
channel. • Dolby Digital 2/0/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1, EX
• Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
Dolby Pro Logic IIx
Music This mode is similar to Dolby Pro Logic II Music, including the availability of center
width, dimension and panorama adjustments. Dolby Pro Logic IIx Music adds a
surround back channel. • Dolby Digital 2/0/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1, EX
• Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
Dolby Pro Logic IIx
Game This mode is similar to Dolby Pro Logic II Game, with the added benefit of a surround
back channel. • Dolby Digital 2/0/.0 or .1
• Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz or 48kHz)
Dolby Pro Logic IIz An expansion of Dolby Pro Logic II that adds left and right front height channels that
are played through two front height speakers mounted above and outside of the front
left and right speakers. • Dolby Digital 2/0/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1, EX
• Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz, 48kHz, 96kHz)
HARMAN virtual
speaker Simulates 5.1 channels when only two speakers are present or a more enveloping
sound field is desired. • Dolby Digital
• Analog (two-channel)
• Tuner
• PCM (32kHz, 44.1kHz or 48kHz)
DTS Digital Using a different encoding/decoding method than Dolby Digital,
DTS Digital also provides up to five discrete main channels, plus an
LFE channel. • DTS 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1, 3/1/.0 or .1, 2/2/.0 or .1,
3/2/.0 or .1
• DTS-ES Matrix (played as 5.1)
• DTS-ES Discrete (played as 5.1)
DTS-HD DTS-HD is a new high-definition audio format that complements the high-definition
video found on Blu-ray Disc and HD-DVD discs. It is transmitted using a DTS core
with high-resolution extensions. Even when only DTS 5.1 surround sound is desired
(or available, if the multizone system is in use), the higher capacity of high-resolution
discs serves up DTS at twice the bit rate used on DVD-Video discs. • Blu-ray Disc or HD-DVD discs encoded with DTS-HD modes,
delivered via HDMI connection
DTS-HD Master Audio DTS-HD Master Audio technology delivers bit-for-bit reproductions of the studio
master recording in up to 7.1 channels for an incredibly accurate performance. • Blu-ray Disc or HD-DVD discs encoded with DTS-HD Master Audio
technology, delivered via HDMI connection
DTS-ES Matrix DTS Extended Surround adds a single surround back channel to DTS 5.1 digital
surround sound. The Matrix version includes the surround back channel information
“matrixed” into the left and right (side) surround channels for compatibility with
5.1-channel systems. • DTS-ES Matrix
DTS-ES Discrete DTS-ES Discrete is another Extended Surround mode that adds a surround back
channel, but this information is encoded discretely on the disc and is not derived
from information contained in the surround channels. • DTS-ES Discrete
DTS Stereo Delivers a two-channel downmix of DTS Digital materials or presents a matrix-
encoded surround presentation. • DTS 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1, 3/1/.0 or .1, 2/2/.0 or .1,
3/2/.0 or .1
• DTS 96/24
• DTS-ES Matrix
• DTS-ES Discrete
Table A12 – Surround Modes – continued
