Reference Materials
A. Appliance Dimension Diagram
Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 5.
Figure 16.1 GDST4336I, GDST4336 Dimensions
Location Inches
Millimeters
I
1-1/2
38
J
27
686
K
8
203
L
12
305
M
9-1/2
241
N
38
965
O
34-5/8
880
P
24
610
Location Inches
Millimeters
A
36
914
B
42-1/2
1080
C
24-1/2
622
D
33-1/2
851
E
1
25
F
2-1/8
54
G
4-1/8
105
H
4-1/4
108
B
C
FRONT VIEW
RIGHT VIEW
ELECTRICAL
ACCESS
GAS LINE
ACCESS
LEFT VIEW
A
P
J
Ø K
L
Ø K
D
F
G
H
M
O
i
N
E
