Connecting to a Video Camera
The following illustration shows you how to connect the TV to a camcorder.
Actual connections may vary according to the make and model of the
device. Refer to the user’s manual included with the camcorder for more
detailed instructions.
WB
S
B
R
W
Y
4-IN-1 cable
S-Video
Cables and connectors are color-
coded (black, red, white, yellow).
AV2
connector
AV connectors
Note: When connecting the
S-Video connector and AV
connectors at the same time,
the priority is given to the S-
Video connector.
