Smart Array P410i
Controller Dimensions
(not including bracket) Low Profile PCIe Form Factor
7.5 in x 9.5 in x 2.25 in (19.05 cm x 24.13 cm x 5.72 cm)
Disk Drive and
Enclosure Interface -
Transfer rate 6Gb/s SAS (Serial Attached SCSI)
3Gb/s SATA (Serial ATA)
SAS Connectors 2 internal (Mini-SAS) x8 wide port connectors
Cache Memory Speed DDR2-800MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s
maximum bandwidth.
Server Interface x8 5G PCIe 2.0 provides 4GB/s maximum bandwidth
SAS Speed x8 3G SAS provides 2.4GB/s maximum bandwidth
Cache Memory 40-bit 256MB ECC protected cache (72-bit 512MB BBWC module
upgrades available); transportable with battery-backed upgrade
Logical Drives
Supported Up to 64 logical drives
Maximum Logical Drive
Capacity Greater than 2TB
Host Memory
Addressing 64-bit, supporting greater than 4GB server memory space
RAID Support RAID 6, 6+0 (Advanced Data Guarding)
NOTE: The minimum of 256 MB cache, battery kit, and Smart Array
Advanced Pack License Key upgrade is required to enable RAID 6, 6+0
RAID 5, 5+0 (Distributed Data Guarding)
NOTE: The 256MB upgrade is required to enable RAID 5 support on the
Smart Array P410i.
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)
Upgradeable Firmware Upgradeable Firmware with recovery ROM feature
NC375i Integrated
Quad Port
Multifunction Gigabit
Server Adapter Network Interface 10Base-T/100Base-TX/1000Base-TX
Compatibility IEEE 802.3 10Base-T
IEEE 802.3ab 1000Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3ad 1000Base-TX
IEEE 802.1p 100Base-TX
IEEE 802.1q 100Base-TX
Data Transfer Method PCI Express, four lanes (x4)
Controller Qlogic/NetXen NX3031
Network Transfer Rate 10Base-T (Half-Duplex) 10 Mb/s
10Base-T (Full-Duplex) 20 Mb/s
100Base-TX (Half-
Duplex) 100 Mb/s
100Base-TX (Full-
Duplex) 200 Mb/s
1000Base-TX (Half and
Full-Duplex) 2000 Mb/s
Connector RJ-45
Cable Support 10Base-T Categories 3, 4 or 5 UTP up to 328 ft (100 m)
100Base-TX Category 5 or higher UTP; up to 328 ft (100
m)
1000Base-TX Category 5 or higher UTP; up to 328 ft (100
m)
