operations. It can withstand two simultaneous drive failures without downtime
or data loss. RAID 10 is mirroring and striping without parity. It is the most
popular of the multiple RAID levels, allowing large arrays with high
performance in most cases and superior fault tolerance. RAID 50 combines
the block striping and parity of RAID 5 with the straight block striping of RAID
0, yielding higher performance than RAID 5 through the addition of RAID 0,
particularly during writes.
Performance Performance Performance Performance Performance numbers are a guideline as established by tests in a lab
environment. Forty-eight 300GB 15K SAS drives were used in
dual controller configurations of four vDisks with 12 physical drives per
vDisk. Each vDisk presented a
single volume of maximum capacity according to RAID level.
Number and type of applications, number of hosts will affect overall
performance.
Workload Workload Workload Workload MSA2012fc MSA2012fc MSA2012fc MSA2012fc MSA2212fc MSA2212fc MSA2212fc MSA2212fc
MSA2000 RAID 10 Performance Results (rounded)
Random Reads IOPs
10,600 11,200
Random Writes IOPs 5,000 7,800
Random Mix IOPs 60/40 read/write 6,700 8,900
Sequential Reads MB 650 1,000
Sequential Writes MBs 330 470
MSA2000 RAID 5 Performance Results (rounded)
Random Reads IOPs 10,200 10,700
Random Writes IOPs 1,700 2,400
Sequential Reads MBs 670 1,000
Sequential Writes MBs 380 580
Random Mix IOPs 60/40 read/write 3,500 5,700
Configuration and Configuration and Configuration and Configuration and
Management Tools
Management Tools Management Tools Management Tools
HP StorageWorks MSA Storage Management Utility (SMU). Management
access, out-of-band: WEB GUI, CLI. Interface Types: Mini DB9 RS232,
10/100 Ethernet Protocols Supported SNMP, SSL, SSH, SMTP, HTTP, Telnet
Hot Plug Expansion and Hot Plug Expansion and Hot Plug Expansion and Hot Plug Expansion and
Replacement Support
Replacement Support Replacement Support Replacement Support
The MSA2000fc supports hot plug expansion and replacement of redundant
controllers, enclosures, fans, power supplies, and I/O modules for simple,
fast installation and maintenance.
Snapshot and Clone Snapshot and Clone Snapshot and Clone Snapshot and Clone Optional controller based functionality. Offers higher levels of data
protection, enabling an almost instant recovery from data failure or
corruption. Offers alternative development testing of 'offline' production data
and the ability to backup snapped/cloned data.
QuickSpecs
HP StorageWorks 2000fc Modular Smart Array HP StorageWorks 2000fc Modular Smart Array HP StorageWorks 2000fc Modular Smart Array HP StorageWorks 2000fc Modular Smart Array
Family Information
DA - 12991 EMEA — Version 5 — September 15, 2008 Page 5
