HP StorageWorks MSA2 300GB 3G 15K 3.5 inch Dual-port SAS HDD
AJ736A
HP StorageWorks MSA2 450GB 3G 15K 3.5 inch Dual-port SAS HDD
AJ737A
HP StorageWorks MSA2 500GB 7.2K 3.5 inch SATA HDD
AJ738A
HP StorageWorks MSA2 750GB 7.2K 3.5 inch SATA HDD
AJ739A
HP StorageWorks MSA2 1TB 7.2K 3.5 inch SATA HDD
AJ740A
Step 2c - Drive Enclosure Options
Step 2c - Drive Enclosure Options
Step 2c - Drive Enclosure Options
Step 2c - Drive Enclosure Options
Should you want a drive enclosure, the model you choose depends on which array model it attaches to. If it is a single controller
array, then choose the JBOD designated as "Single I/O". If it is attaching to a dual controller array then choose the "Dual I/O" JBOD
HP StorageWorks MSA2000 Single I/O 3.5 in 12 Drive Enclosure
AJ749A
HP StorageWorks MSA2000 Dual I/O 3.5 inch 12 Drive Enclosure
AJ750A
SAS Cables
SAS Cables
SAS Cables
SAS Cables
HP Ext SAS 1m Cable
389665-B21
HP Ext SAS 2m Cable
389668-B21
HP Ext SAS 4m Cable
389671-B21
Step 3 - Other MSA2000fc Options
Step 3 - Other MSA2000fc Options
Step 3 - Other MSA2000fc Options
Step 3 - Other MSA2000fc Options
Description
Description
Description
Description
Quantity
Quantity
Quantity
Quantity
Part Number
Part Number
Part Number
Part Number
HP StorageWorks 2000fc Modular Smart Array Controller
(for future upgrading of a single controller Fibre Channel array to a dual controller model)
AJ744A
HP StorageWorks MSA2000 Drive Enclosure I/O Module
(for future upgrading of a single I/O 3.5" Disk Enclosure to a dual controller model)
AJ751A
Choose optional Power Cord for Non-U.S. Configurations
Choose optional Power Cord for Non-U.S. Configurations
Choose optional Power Cord for Non-U.S. Configurations
Choose optional Power Cord for Non-U.S. Configurations
NOTE:
NOTE:
NOTE:
NOTE: Shipped standard with all units.
2 ea. Power Cord, 110/220 VAC, US/Canada/Mexico 227099-001
Power Cord, 220/240 VAC, (US/Canada/Mexico)
2
227099-001
Power Cord, (Australia/China/New Zealand)
2
227098-001
Power Cord, (Central Europe)
2
157215-001
Power Cord, (United Kingdom/Hong Kong)
2
157216-001
Power Cord, (Switzerland)
2
157219-001
Power Cord, (Italy)
2
157217-001
Power Cord, (Denmark)
2
157218-001
Power Cord, (Japan)
2
139867-001
Power Cord, (South East Asia/India)
2
157220-001
Step 4 - Choose Supported Options For Fibre Channel Infrastructure
Step 4 - Choose Supported Options For Fibre Channel Infrastructure
Step 4 - Choose Supported Options For Fibre Channel Infrastructure
Step 4 - Choose Supported Options For Fibre Channel Infrastructure
Fibre Channel
Fibre Channel
Fibre Channel
Fibre Channel
Host Bus Adapters
Host Bus Adapters
Host Bus Adapters
Host Bus Adapters
Model
Model
Model
Model
Description
Description
Description
Description
Part Number
Part Number
Part Number
Part Number
FC2242SR
4Gb PCI-E Dual Channel HBA for Windows (future Linux
support)
A8003A
FC2142SR
4Gb PCI-E for Windows (future Linux support)
A8002A
QuickSpecs
HP StorageWorks 2000fc Modular Smart Array
HP StorageWorks 2000fc Modular Smart Array
HP StorageWorks 2000fc Modular Smart Array
HP StorageWorks 2000fc Modular Smart Array
Configuration Information
DA - 12991 EMEA — Version 5 — September 15, 2008
