Dual Controller MSA2000fc Dual Controller MSA2000fc Dual Controller MSA2000fc Dual Controller MSA2000fc
1. Expansion Port 4. Service Port
2. Ethernet Port 5. Fibre Channel Ports
3. CLI Port 6. Power Switch
MSA2000 Dual I/O 3.5" 12 Drive Enclosure MSA2000 Dual I/O 3.5" 12 Drive Enclosure MSA2000 Dual I/O 3.5" 12 Drive Enclosure MSA2000 Dual I/O 3.5" 12 Drive Enclosure
1. Service Port 5. AC Power Good
2. Unit Locator 6. SAS In Port
3. Power Switch 7. SAS Out Port
4. DC Voltage / Fan Fault
QuickSpecs
HP StorageWorks 2000fc Modular Smart Array HP StorageWorks 2000fc Modular Smart Array HP StorageWorks 2000fc Modular Smart Array HP StorageWorks 2000fc Modular Smart Array
Configuration Information
DA - 12991 EMEA — Version 5 — September 15, 2008 Page 16
