28
ENGLISH
PRODUCT SPECIFICATIONS
Product specifications and designs are subject to change without notice.
The monitor takes at least 30 minutes to attain the status of optimal picture quality.
Use RGB input signals in non-interlaced mode.
2,090,000 colors / 16,700,000 colors
Display color
adjustment
External dimensions
Type CMP307XU
Input
signals
Input
terminals
RGB1 input terminal : mD-Sub 15 pin x 1
RGB2 input terminal : BNC x 5
RGB audio input terminal : RCA pin (L/R) x 1
Sync signals
H/V separate, TTL level
H/V composite, TTL level
Sync on green, 0.3 Vp-p
Synchroniz
ing signal
frequency Horizontal 24kHz ~ 64kHz
Vertical 50Hz ~ 75Hz
Video clock frequency 108MHz or less
Plasma
Display
Panel
Effective
screen size
Approx. 37inches, Aspect ratio 4:3 (753 mm (H), vertical 564 mm (V))
No. of pixels 1024 (H) x 768 (V) pixels
Input power
AC100 - 120 / 200 - 240V(automatically selected) 4.3A / 2.2A
Power consumption 390W
Mass
884 (W) x 684 (H)x 99.7 (D) (mm) : (excluding the stand)
884 (W) x 766 (H)x 300 (D) (mm) : (including the stand)
Ambient
conditions
---
---
---
---
---
---
VIDEO1 video input terminal : Composite video
RCA pin x 1
VIDEO1 S video input terminal : S VIDEO,
S terminal x 1
VIDEO1 audio input terminal : RCA pin (L/R) x 1
VIDEO2 video input terminal : Composite video
RCA pin x 3
(Y,P
B /P R ,C B /C R )
VIDEO2 audio input terminal : RCA pin (L/R) x 1
Temperature Operating: 5˚C to 35˚C, Storage : 0˚C to 40˚C
Relative
humidity
Operating: 20% to 80%, Storage : 20% to 90% (non-condensing)
29.8 kg (excluding the stand), 32.8 kg (including the stand)
Speaker output 2W+2W (EIAJ) (10cm x 3cm built-in speaker x 2)
Audio signals L/R 470mV, high impedance L/R 470mV, high impedance
Video signals 0.7 V/1.0 Vp, analog RGB NTSC, 480i, 480p, 720p, 1080i
RGB input VIDEO input
Viewing angle Horizontal/vertical 160 degrees or more.
Brightness /
contrast
150cd/m 2 (brightness) at white peak; 400: 1 (standard) in a dark room.
Pixel pitch 0.735mm (H) x 0.735mm (V)
Color density
(at white peak)
9300K + 6MPCD (normal) 9400K - 9MPCD (normal)
General Specifications
