System Unit Dimensions Height 14.42 in (36.63 cm)
Depth 20.05 in (50.93 cm)
Width 4.10 in (10.41 cm)
Shipping Dimensions Height 21.50 in (54.61 cm)
Depth 23.13 in (58.75 cm)
Width 9.94 in (25.25 cm)
Weight Maximum 38 (17 kg)
Temperature Range * Operating 10° to 35° C (50° to 95° F)
Non-Operating -40° to 60° C (-40° to 140° F)
Storage -20° to 60° C (-4° to 140° F)
Maximum Wet Bulb
Temperature 30° C (86° F)
Relative Humidity ** Operating 10% to 90%
Shipping 10% to 90%
Storage 10% to 95%
*All temperature ratings shown are for sea level. An altitude derating of 1°C per 304.8 m (1.8°F
per 1,000 ft) to 3048 m (10,000 ft) is applicable. No direct sunlight allowed. Upper operating limit
is 3,048m (10,000 ft) or 70 Kpa/10.1 psia. Upper non-operating limit is 9,144 m (30,000 ft) or 30.3
KPa/4.4 psia.
**Storage maximum humidity of 95% is based on a maximum temperature of 45°C (113°F).
Altitude maximum for storage corresponds to a pressure minimum of 70 KPa.
SAS RAID LSI 1068
Controller Disk Drive and
Enclosure Interface 3G SAS (Serial Attached SCSI)
SAS Connectors 1 internal mini-SAS x4 wide port connector
Server Interface PCI-X 66MHz 64-bit provides 0.5GB/s maximum bandwidth
SAS Speed x4 3G SAS provides 1.2GB/s maximum bandwidth.
Cache Memory No cache memory supported
Logical Drives
Supported Up to 32 logical volumes
Maximum Logical Drive
Capacity 584GB (4 x 146GB)
Host Memory
Addressing 64-bit, supporting greater than 4GB server memory space
RAID Support RAID 1 (Mirroring)
Upgradeable Firmware Upgradeable Firmware
QuickSpecs
HP Integrity BL870c Server Blade
Technical Specifications
