DIMM installation guidelines:
All DIMMs must be PC2-4200 DIMMs (DDR2 533MHz) 1.
All four DIMM slots in a memory bank must be populated. 2.
Banks must be populated in sequential numeric order, starting with bank 0. 3.
All four DIMMs in a memory bank must be identical. Install identical DIMMs in quads, starting with DIMM socket A,
bank 0. 4.
DIMMs must be installed in decreasing capacity with the largest DIMMs installed in the smallest numbered DIMM slot. 5.
HP Integrity BL870c Server Blade
Standard Memory
4GB Registered PC2-4200, DDR2 533MHz ECC DIMMs (4 x 1 GB)
Memory Bus Bandwidth:17 GB/s
Standard Memory Plus Optional Memory
Up to 96GB of PC2-4200, DDR2-533 DIMMs memory is available.
Memory Slot
Standard 4GB 0A 0B 0C 0D 2A 2B 2C 2D 4A 4B 4C 4D
1GB 1GB 1GB 1GB Empty Empty Empty Empty Empty Empty Empty Empty
1A 1B 1C 1D 3A 3B 3C 3D 5A 5B 5C 5D
Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty Empty
Maximum 96GB 0A 0B 0C 0D 2A 2B 2C 2D 4A 4B 4C 4D
4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB
1A 1B 1C 1D 3A 3B 3C 3D 5A 5B 5C 5D
4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB 4GB
Following are memory options available from HP:
4GB PC2-4200 DDR2-5300 Quad Memory AH252A
8GB PC2-4200 DDR2-5300 Quad Memory AH253A
16GB PC2-4200 DDR2-5300 Quad Memory AH254A
NOTE: Must be installed in quads.
NOTE: DIMMs must be installed in decreasing capacity with the largest DIMMs smallest numbered slot.
QuickSpecs
HP Integrity BL870c Server Blade
Memory
DA - 12926 Worldwide QuickSpecs — Version 1 — 2.11.2008 Page 23
