Expansion Slots Bus speed Bus number PCI Voltage Notes
1 64-bit / 100 MHz PCI-X Bus 0x42 = 66 3.3 Volt Half-length Slot
2 64-bit / 100 MHz PCI-X Bus 0x42 = 66 3.3 Volt
3 PCI-Express x4 Bus 0x49 = 73
4 PCI-Express x4 Bus 0x4C = 76
5 PCI-Express x8 Bus 0x46 = 70
6 PCI-Express x4 Bus 0x4F = 79
7 PCI-Express x8 Bus 0x02 = 2
8 PCI-Express x8 Bus 0x05 = 5
9 PCI-Express x4 Bus 0x08 = 8 Half-length slot;
Reserved slot for
Smart Array P400
Controller
NOTE: All slots are non-hot-plug Default bus assignment. Inserting cards with PCI bridges may alter the actual bus
assignment number. Slots are enumerated differently based on the operating system. Microsoft operating systems
enumerate from lowest to highest Device ID by bus (starting with the lowest bus).
Manageability Integrated Lights-Out 2 (iLO 2) Standard Management (ASIC on the System Board)
Storage Controllers
One of the following
depending on Model
HP Smart Array P400/256MB Controller (in a PCI-Express slot)
NOTE: Standard on 2.0GHz and 2.2GHz models.
HP Smart Array P400/512MB BBWC Controller (in a PCI-Express slot)
NOTE: Standard on 2.4GHz, 2.6GHz, 2.8GHz, and 3.0GHz models.
Storage Data
Protection The Battery-Backed Write Cache (BBWC) Enabler for the Smart Array P400 Controller protects up
to 512-MB write cache memory from hard boot, power, controller, or system board failures.
Standard on all HP ProLiant DL585 G2 Models
Battery charge/life: Up to 72 hours/3 years
Transportable data protection
Increases overall controller performance
NOTE: Safely transport your write cache data to another HP ProLiant DL585 G2 in the data center
by removing the BBWC Enabler and Smart Array P400 Controller Memory Module simultaneously
(connected by short cable).
Storage Diskette Drive Optional 1.44 MB Diskette Drive (slimline) - ejectable for security and
serviceability
Optical Drive Slimline DVD/CD-RW Drive Standard on all models - ejectable for
security and serviceability
Hard Drives None ship standard
Hard Disk Drive
Backplane Internal SAS backplane supports up to eight SFF hard disk drives
QuickSpecs
HP ProLiant DL585 Generation 2
Standard Features
DA - 12575 U.S. QuickSpecs — Version 28 — 11/27/2007 Page 4
