Standard Memory Configuration (2.8GHz models)
Total Memory = 8 GB
1
(Slot
furthest
from
processor)
2 3 4 5 6 7 8
(Slot
closest to
processor)
Processor 1 Memory Bus 1 GB 1 GB Empty Empty Empty Empty Empty Empty
Processor 2 Memory Bus 1 GB 1 GB Empty Empty Empty Empty Empty Empty
Processor 3 Memory Bus 1 GB 1 GB Empty Empty Empty Empty Empty Empty
Processor 4 Memory Bus 1 GB 1 GB Empty Empty Empty Empty Empty Empty
Examples of other optional configurations include, but are not limited to:
Example #1: Optional Memory Configuration with DIMM mixing
Standard Memory plus Optional Memory and Processors
Total Memory = 34 GB
1 2 3 4 5 6 7 8
Processor 1 Memory Bus 2 GB 2 GB 1 GB 1 GB 512 MB 512 MB 512 MB 512 MB
Processor 2 Memory Bus 2 GB 2 GB 1 GB 1 GB 512 MB 512 MB 512 MB 512 MB
Processor 3 Memory Bus 2 GB 2 GB 2 GB 2 GB 1 GB 1 GB 512 MB 512 MB
Processor 4 Memory Bus 1 GB 1 GB 1 GB 1 GB 1 GB 1 GB 512 MB 512 MB
Example #2: Optional Memory Configuration with Partial Bus Population
Standard Memory plus Optional Memory and Processors
Total Memory = 8 GB
1 2 3 4 5 6 7 8
Processor 1 Memory Bus 512 MB 512 MB 512 MB 512 MB Empty Empty Empty Empty
Processor 2 Memory Bus 512 MB 512 MB 512 MB 512 MB Empty Empty Empty Empty
Processor 3 Memory Bus 512 MB 512 MB 512 MB 512 MB Empty Empty Empty Empty
Processor 4 Memory Bus 512 MB 512 MB 512 MB 512 MB Empty Empty Empty Empty
Example #3: Maximum Memory Configuration
Maximum Memory (Standard replaced with Optional Memory)
Total Memory = 128 GB
1 2 3 4 5 6 7 8
Processor 1 Memory Bus 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB
Processor 2 Memory Bus 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB
Processor 3 Memory Bus 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB
Processor 4 Memory Bus 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB
QuickSpecs
HP ProLiant DL585 Generation 2
Memory
DA - 12575 U.S. QuickSpecs — Version 28 — 11/27/2007 Page 34
