NOTE: Memory configurations listed do not apply to "Factory Integrated Models."
HP ProLiant DL585 G2 2P Models
Standard Memory
4 GB PC2-5300 Double Data Rate 2 (DDR2) SDRAM (Registered SDRAM) memory running at 667 MHz or
2 GB PC2-5300 Double Data Rate 2 (DDR2) SDRAM (Registered SDRAM) memory running at 667 MHz with Advanced
ECC
At least one pair of DIMMs must be installed in slots 1A and 2A to operate the server. Observe the following DIMM
installation guidelines to add additional memory to the server:
DIMMs must be installed in pairs.
DIMM installed on the same memory bank must have the same part number.
DIMMs installed in different banks can be of different sizes.
DIMMs must be installed in decreasing capacity with the largest DIMMs installed in the banks furthest away from each
processor.
DIMM banks are active only when the corresponding processor socket is populated.
NOTE: If all four banks on a memory node are populated, the maximum memory clock speed will be 533 MHz. If two or
fewer banks on a memory node are populated, the maximum memory clock speed will be 667 MHz.
The following memory options are available from HP:
1 GB REG PC2-5300 (2 x 512 MB) single rank 408850-B21
2 GB REG PC2-5300 (2 x 1 GB) single rank 408851-B21
4 GB REG PC2-5300 (2 x 2 GB) dual rank 408853-B21
8 GB REG PC2-5300 (2 x 4 GB) dual rank 408854-B21
Standard Memory Configuration (2.0GHz, 2.2GHz and 2.4GHz models)
Total Memory = 2 GB
1
(Slot
furthest
from
processor)
2 3 4 5 6 7 8
(Slot
closest to
processor)
Processor 1 Memory Bus 512 MB 512 MB Empty Empty Empty Empty Empty Empty
Processor 2 Memory Bus 512 MB 512 MB Empty Empty Empty Empty Empty Empty
Processor 3 Memory Bus Empty Empty Empty Empty Empty Empty Empty Empty
Processor 4 Memory Bus Empty Empty Empty Empty Empty Empty Empty Empty
Standard Memory Configuration (2.6GHz model)
Total Memory = 4 GB
1
(Slot
furthest
from
processor)
2 3 4 5 6 7 8
(Slot
closest to
processor)
Processor 1 Memory Bus 1 GB 1 GB Empty Empty Empty Empty Empty Empty
Processor 2 Memory Bus 1 GB 1 GB Empty Empty Empty Empty Empty Empty
Processor 3 Memory Bus Empty Empty Empty Empty Empty Empty Empty Empty
Processor 4 Memory Bus Empty Empty Empty Empty Empty Empty Empty Empty
QuickSpecs
HP ProLiant DL585 Generation 2
Memory
DA - 12575 U.S. QuickSpecs — Version 28 — 11/27/2007 Page 33
