56
SONAR MENU TAB
Press the MENU key twice to access the Main
Menu System and then press the RIGHT Cursor
key to select the Sonar tab.
NOTE: Menu choices will vary depending on system
settings such as whether the unit is set for Advanced
User mode or whether a 2D or a 3D View is
displayed/active.
2D SONAR COLORS
2D Sonar Colors allows you to select which color
palette you would like to use for the display.
To change the 2D Sonar Colors:
1. Highlight 2D Sonar Colors on the 2D Sonar menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the color palette.
(Standard, Gray, Inverse, Green, Default = Standard)
3D BOTTOM STYLE
3D Bottom Style selects the bottom style
used in the 3D Sonar View.
To change the 3D Bottom Style setting:
1. Highlight 3D Bottom Style on the Sonar main menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the 3D Bottom Style
setting. (Grid Only, Shaded with Grid, Shaded, Default = Shaded with Grid)
3D FRAME STYLE
3D Frame Style selects the frame style used
in the 3D Sonar View.
To change the 3D Frame Style setting:
1. Highlight 3D Frame Style on the Sonar main menu.
2. Use the LEFT or RIGHT 4-WAY Cursor Control keys to change the 3D Frame Style
setting. (Simple, 2, 3, 4, Complex, Default = 3)
Sonar Menu
