SIDE/SONAR COMBO VIEW
Side/Sonar Combo View shows regular sonar information and side imaging sonar
information in a combination split screen. You can perform any of the functions for
either of these views, but only when the view you want to control is selected as the
active side (see Sonar X-Press™ Menu: Active Side or Side Imaging X-Press™ Menu:
Active Side for more information). You can also adjust the size of the left side of a split
screen (see Sonar X-Press™ Menu: Split Position or Side Imaging X-Press™ Menu: Split
Position for more information).
In this view, you can change which side you look at, the sensitivity of the sonar to allow
you to see more or less, the range of the side beams, the scrolling speed of the chart,
and the color scheme of the display, all from the Side Imaging X-Press™ menu. See Side
Imaging X-Press™ Menu for more information.
NOTE: See Side Imaging View and Sonar View for more information about each side of this view.
Side/Sonar Combo View
Depth Water Column 1 6
Bearing of Boat with Respect to North Reference Shadows 2 7
Water Surface Temperature Topography Changes 3 8
Speed Bottom Return 4 9
Fish ID Boat Icon 5 10
1
4
3
2
5
6
7
8
9
10
37
