7
2. KM-2500SRH3 (remote air-cooled)
Note: We reserve the right to make changes in specifications and design without prior
notice.
AC SUPPLY VOLTAGE 208-230/60/3
AMPERAGE 17.7 A ( 5 Min. Freeze AT 104°F / WT 80°F)
MINIMUM CIRCUIT AMPACITY 30 A
MAXIMUM FUSE SIZE 30 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp.(°F) 50 70 90
lbs./day ( kg/day ) 70 *2424 (1100) 2373 (1076) 2196 (996)
Reference without *marks 80 2385 (1082) 2306 (1046) 2069 (939)
90 2373 (1076) *2250 (1021) 2035 (923)
100 2301 (1044) 2200 (998) 1837 (833)
SHAPE OF ICE Crescent Cube
ICE PRODUCTION PER CYCLE 46.1 lbs. (20.9 kg) 2160pcs.
APPROXIMATE STORAGE CAPACITY N/A
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 4220(4.5) 3780(3.7)
WATER gal./24HR (gal./100 lbs.) 419(18.6) 791(32.6)
CEC/CEE TIER LEVEL 2
ENERGY STAR YES
EXTERIOR DIMENSIONS (WxDxH) 48" x 27-3/8" x 36-7/16" (1219 x 695 x 925 mm)
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 390 lbs. (177 kg), Shipping 440 lbs. (200 kg)
CONNECTIONS - ELECTRIC Permanent - Connection
- WATER SUPPLY Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT
3/8" OD Tube
CUBE CONTROL SYSTEM Float Switch
HARVESTING CONTROL SYSTEM Hot Gas and Water, Thermistor and Timer
ICE MAKING WATER CONTROL Timer Controlled. Overflow Pipe
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM Thermostat
COMPRESSOR Hermetic, Model MTZ-57-HL3A
CONDENSER Air-Cooled Remote, Condenser Unit URC-23F
EVAPORATOR Vertical type, Stainless Steel and Copper
REFRIGERANT CONTROL Thermostatic Expansion Valve
Condensing Pressure Regulator on Icemaker (190 PSI)
REFRIGERANT CHARGE R404A, 24 lb. 7.5 oz. (11100g)
(Icemaker 14 lbs. 12.3 oz. Cond. Unit 9 lbs. 11.2 oz.)
DESIGN PRESSURE High 467PSIG, Low 230PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-out ( Internal )
COMPRESSOR PROTECTION Auto-reset Overload Protector ( Internal )
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch
ACCESSORIES -SUPPLIED N/A
-REQUIRED Ice Storage Bin, Remote Condenser Unit
OPERATING CONDITIONS VOLTAGE RANGE 187 - 253 V
AMBIENT TEMP. 45 -100° F
WATER SUPPLY TEMP. 45 - 90° F
WATER SUPPLY PRESSURE 10 - 113 PSIG
ENG.F-011.1.0205
