II. General Information
A. Construction
1. KM-2500SWH3 (water-cooled)
Main Transformer
Box
Evaporator Assembly
Spray Tubes
Inlet Water Valve
Water Supply Inlet
Hot Gas Valve
Junction Box
Water
Regulating
Valve
Service Valves
Control Box
Liquid Line Valve
Drier
Control Switch
Bin Control Thermostat
Compressor
Cleaning Valve
Float Switch
Water Pump
Check Valve
(water)
Expansion Valves
Strainer
Bin Control Thermostat Bracket
Bin Control Bulb Holder
Check Valves
(Refrigeration Circuit)
Condenser
Bin Control "Z" Bracket
Bin Control Extension Bracket
