6
I. Specifications
A. Icemaker
1. KM-2500SWH3 (water-cooled)
Note: We reserve the right to make changes in specifications and design without prior
notice.
AC SUPPLY VOLTAGE 208-230/60/3
AMPERAGE 14.2 A ( 5 Min. Freeze AT 104°F / WT 80°F)
MINIMUM CIRCUIT AMPACITY 30 A
MAXIMUM FUSE SIZE 30 A
APPROXIMATE ICE PRODUCTION Ambient WATER TEMP. (°F)
PER 24 HR. Temp.(°F) 50 70 90
lbs./day ( kg/day ) 70 *2408 (1092) 2395 (1087) 2256 (1024)
Reference without *marks 80 2398 (1088) 2379 (1079) 2172 (985)
90 2395 (1087) *2365 (1073) 2184 (991)
100 2327 (1055) 2323 (1054) 2018 (915)
SHAPE OF ICE Crescent Cube
ICE PRODUCTION PER CYCLE 46.3 lbs. (21 kg) 2160pcs.
APPROXIMATE STORAGE CAPACITY N/A
ELECTRIC & WATER CONSUMPTION 90/70°F 70/50°F
ELECTRIC W (kWH/100 lbs.) 3720(3.78) 3510(3.5)
WATER gal./24HR (gal./100 lbs.) 459(19.4) 744(30.9)
WATER COOLED CONDENSER 1430(101) 1430(59)
gal./24HR (gal./100 lbs.)
CEC/CEE TIER LEVEL 1
ENERGY STAR N/A
EXTERIOR DIMENSIONS (WxDxH) 48" x 27-3/8" x 36-7/16" (1219 x 695 x 925 mm)
EXTERIOR FINISH Stainless Steel, Galvanized Steel (Rear)
WEIGHT Net 390 lbs. (177 kg), Shipping 415 lbs. (188 kg)
CONNECTIONS - ELECTRIC Permanent - Connection
- WATER SUPPLY Inlet 1/2" FPT Condenser Inlet 1/2" FPT
- DRAIN Outlet 3/4" FPT Condenser Outlet 1/2" FPT
3/8" OD Tube
CUBE CONTROL SYSTEM Float Switch
HARVESTING CONTROL SYSTEM Hot Gas and Water, Thermistor and Timer
ICE MAKING WATER CONTROL Timer Controlled. Overflow Pipe
COOLING WATER CONTROL N/A
BIN CONTROL SYSTEM Thermostat
COMPRESSOR Hermetic, Model CS27K6E-TF5-237
CONDENSER Water Cooled, Tube in Tube Type
EVAPORATOR Vertical type, Stainless Steel and Copper
REFRIGERANT CONTROL Thermostatic Expansion Valve
REFRIGERANT CHARGE R404A, 4 lb. 11.5 oz. (2140g)
DESIGN PRESSURE High 427PSIG, Low 230PSIG
P.C. BOARD CIRCUIT PROTECTION High Voltage Cut-out ( Internal )
COMPRESSOR PROTECTION Auto-reset Overload Protector ( Internal )
REFRIGERANT CIRCUIT PROTECTION Auto-reset High Pressure Control Switch
LOW WATER PROTECTION Float Switch
ACCESSORIES -SUPPLIED N/A
-REQUIRED Ice Storage Bin
OPERATING CONDITIONS VOLTAGE RANGE 187 - 253 V
AMBIENT TEMP. 45 -100° F
WATER SUPPLY TEMP. 45 - 90° F
WATER SUPPLY PRESSURE 10 - 113 PSIG
ENG.F-011.1.0205
