HANNspree F651-12C1 User Manual
Making connections, A/v and channel setup, Getting started
Auto Channel Setup
1. Press the
MENU button to enter the OSD menu.
Please follow the instructions by using the control panel.
6. Your television will begin automatically memorizing the available channels.
4. Press the
CH - button until the "Auto Program" feature is selected.
2. Use the
CH - button to select "TV".
5. Press the
VOL + button to begin "Auto Program".
3. Press the
VOL + button to enter the TV setting.
Quick Start Guide
Front View & Rear View
Front View & Rear View
Copyright 2005, Hannspree, Inc. All rights reserved.
Making Connections
Connecting to a VCR, VCD, DVD Player, or Video Game Console
Connecting the Power Adapter
2. The cables are
color-coded (black,
red, white, and
yellow). Connect
each color-coded
cable to the
appropriate
connector on your
device.
1. The illustration presented
here shows you how to
connect your TV to a
VCR, VCD, DVD
player or video
game console.
Connecting to Antenna/Cable TV
A/V and Channel Setup
MAD-001308
Power indicator LED
Channel
select
Volume
adjust
Remote IR sensor
1. Connect one end of the VHF/UHF
(Antenna) or CATV cable to ANT Jack
(VHF/UHF IN Jack) on the back of the
TV.
2. Connect the other end of the VHF/UHF
(Antenna) or CATV cable to the Antenna
or CATV socket.
1. Connect the power cord to the power
adapter as illustrated.
2. Plug the power adapter connector into
the DC-IN input jack on the rear panel
of the TV.
3. Insert the three-pronged plug at the
other end of the power cord into a
power outlet.
F651-12C1 12.1" Liquid Crystal Display TV
This guide is designed as a reference to help you start using your LCD TV quickly. Please refer to the User's Manual for more detailed installation and safety instructions.
Headphone jack
AV IN
ANT
DC-IN HEADPHONE
-2
0
-1
0
0
10
20
30
4
0
50
THERMOMETER
60
50
40
30
20
1
0
-10
0
70
80
90
10
0
11
0
12
0
130
50
40
30
20
10
0
60
70
80
90
10
0
%
HYGROMETER
CF
QUARTZ
05
10
1
5
20
25
30
35
40
4
5
50
55
XII
X
X
X
I
II
III
IIII
I
V
V
II V
III
I
I
V
Thermometer/Hygrometer
Clock
AV
DC-IN
Antenna/Cable TV
MENU
CH -
CH +
VOL -
VOL +
SOURCE
Power
Source
Speaker
Speaker
Menu
Getting Started
Placing the Clock and Thermometer/Hygrometer
1. Turn the clock so that the screw points to
the 11 o'clock position as shown (A).
2. Turn the clock face clockwise as shown (B).
The clock is locked into place.
Thermometer/Hygrometer
Clock
1. Turn the Thermometer/Hygrometer so that
the screw points to the 5 o'clock position
as shown (A).
2. Turn the Thermometer/Hygrometer face
clockwise as shown (B).
The Thermometer/Hygrometer is locked
into place.
Removing the Clock and Thermometer/Hygrometer
Thermometer/Hygrometer
Clock
1. Hold the Thermometer/Hygrometer and twist
it counterclockwise as shown to unlock it.
2. Remove the Thermometer/Hygrometer.
1. Hold the clock and twist it counterclockwise
as shown to unlock it (A).
2. Remove the clock (B).
Note: Place your fingers as shown to avoid
damage to the LCD panel.
DC-IN
Power cord
Power outlet
Power adapter
AV IN
ANT
DC-IN HEADPHONE
ANT jack
(VHF/UHF IN Jack)
Antenna/CATV
coaxial cable
Antenna
AV IN
ANT
DC-IN HEADPHONE
MENU
CH -
CH +
VOL -
VOL +
SOURCE
TV
AV
Video game
console
4-IN-1 A/V cable
4-IN-1 A/V jack
AV connectors
S-Video
connector
VCR
DVD
VCD
AV IN
ANT
DC-IN HEADPHONE
B R W Y
B
R
W
Y
Selecting A/V Sources
1. Make sure your TV is turned on and a
device such as a DVD player is connected.
2. Press the
SOURCE button on the
control panel to select different source signals.
TV channel number, AV or AVs appear on the screen.
Note : AVs only appears on the screen when
S-Video is connected.
TV
Auto-Programming
093.84 MHz
1
6%
Return :
MENU
Auto Program
Note :
Images are for illustration only and may
vary by model or region.
