Maximum Color
Depth 32 bits/pixel
Maximum Vertical
Refresh Rate 85 Hz at up to 1920x1440, 75 Hz at 2048x1536. Varies with mode and
configuration. See table below.
Multi-display Support Integrated dual independent monitor support facilitated via one VGA port and
one DisplayPort integrated on the back plane of the system board and
presented as part of the rear I/O set of interfaces. DVI supported via optional
HP DisplayPort to DVI-D adapter.
Graphics/Video API
Support Microsoft DirectX® 10, OpenGL® 1.5 (OpenGL® 2.0 available in a driver
update)
Resolutions Supported
NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP.
Maximum Refresh Rate (Hz)
Resolution Analog Connection Digital Connection
640x480 85 60
800x600 85 60
1024x768 85 60
1280x720 85 60
1280x1024 85 60
1440x900 75 60
1600x1200 85 60
1680x1050 75 60
1920x1080 85 60-R
1920x1200 85 60-R
1920x1440 85 N/A
2048x1536 75 N/A
2560x1600 N/A 60 *
* Only supported when using a DisplayPort connection
NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital
connections.
NVIDIA Quadro NVS
290 PCIe x1 Graphics
Card Bus type PCIe x1
Low profile, both ATX and low profile brackets included
Graphics Controller Integrated Quadro 290 2D graphics processor unit (GPU)
Memory 256 MB DDR2
Connector Single high-density DMS-59 Flex Connector
Dimensions Low-profile, 2.586 x 6.6 in (6.57 x 16.76 cm)
Multi-monitor support Dual analog or digital (Single Link DVI) monitors
(DVI support requires optional DVI cable kit DL139A)
RAMDAC Dual 350 MHz (integrated)
Maximum pixel clock 350 MHz
Overlay planes One 1-bit Video overlay plane
High-definition Video
Processor (HDVP) Full screen, full frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling
Input/Output connectors DMS-59
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications - Graphics
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 33
