PCI Express x16 Slot
(Supports discrete
graphics cards) N/A 1 slot
low profile – 2.5"
length – 6.6"
max. power –25W 2 slots
full height – 4.2"
full length
max. power – 75W (primary)
max. power – 35W
(secondary)
PCI Express x1 Slot N/A 2 slots
low profile – 2.5"
length – 6.6"
max. power – 10W 1 slot
half height – 2.5"
half length
max. power – 10W
Bays Ultra-slim Desktop Small Form Factor Convertible Minitower
3.5" external N/A 1 bay available for Media Card
Reader unless used for a
secondary hard drive N/A
5.25" external N/A 1 bay – 8.19" depth 3 bays
Top two bays accept drives
up to 8.19" depth
Bottom bay accepts drives
up to 5.7" depth
Slimline 1 bay for ODD N/A N/A
Secure Digital (SD)
Reader SD Reader or blank N/A N/A
Internal Drive Bays 1 bay for 2.5" drive 1 bay for 3.5" drive 3 bays for 3.5" drives
Controller Ultra-slim Desktop Small Form Factor Convertible Minitower
Hard Drive Controller Serial ATA
Supports SATA 1.5-GB/s and 3.0-GB/s
SATA Interfaces (1) Total (4) Total:
(3) common SATA
(1) eSATA (5) Total:
(4) common SATA
(1) eSATA
Host SATA Controller Advanced Host Controller Interface (AHCI) Revision 1.2. The specification includes a description
of the hardware/software interface between system software and the host controller hardware.
Unit Environment and Operating Conditions
General Unit Operating Guidelines
Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that
unit is operated within the specified operating range.
Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.
Never restrict airflow into the computer by blocking any vents or air intakes.
Do not stack computers on top of each other or place computers so near each other that they are subject to each
other's re-circulated or preheated air.
Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other
foreign matter can block the vents and limit the airflow.
If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the
enclosure, and the same operating guidelines listed above will still apply.
Temperature Range Operating: 50° to 95° F (10° to 35° C) *
Non-operating: –22° to 140° F(–30° to 60° C)
Relative Humidity Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized) Operating: 10,000 ft (3048 m)
Non-operating: 30,000 ft (9144 m)
QuickSpecs
HP Compaq 8000 Elite PC
Technical Specifications
DA - 13424 Worldwide QuickSpecs — Version 17 — 6/25/2010 Page 19
