2. DCM-750BWH(-OS)
Inlet Water Valve
Dispensing Water Valve
Drain Valve
Float Switch
Water Level
To Drain
Evaporator
Spout
Expansion Valve
Gear Motor
Overflow
Reservoir
Water Supply
Drier
Water-Cooled Condenser
High Pressure Switch
Access Valve
Access Valve
Compressor
Water Supply In
Water Supply Out
Refrigeration Circuit
Water Circuit
Water Regulating
Valve
