Operating and Operating and Operating and Operating and
Performance
Performance Performance Performance
Specifications for
Specifications for Specifications for Specifications for
ProLiant BL p-Class
ProLiant BL p-Class ProLiant BL p-Class ProLiant BL p-Class
Power Enclosures
Power Enclosures Power Enclosures Power Enclosures
Single-Phase Model Single-Phase Model Single-Phase Model Single-Phase Model 3-Phase Model 3-Phase Model 3-Phase Model 3-Phase Model
Dimensions Dimensions Dimensions Dimensions Height 5.25 in (13.34 cm) 5.25 in (13.34 cm)
Width 27.15 in (68.96 cm) 27.15 in (68.96 cm)
Depth 17.60 in (44.7 cm) 17.60 in (44.7 cm)
Weights Weights Weights Weights No Hot-Plug
Power Supplies 47.5 lb (21.55 kg) 47.5 lb (21.55 kg)
All Hot-Plug
Power Supplies 99.5 lb (45.13 kg) 125.5 lb (56.93 kg)
Input Requirements Input Requirements Input Requirements Input Requirements Rated input voltage 200 VAC to 240 VAC 200 VAC to 240 VAC line to
line
Rated input frequency 50 Hz to 60 Hz 50 Hz to 60 Hz
Rated input current
per side 24A 24A per phase
Rated input power
per side 5760 W 9976 W
Power cord 1 NEMA L6-30P per side 1 NEMA L15-30 per side
Output Voltage Output Voltage Output Voltage Output Voltage
Specifications
Specifications Specifications Specifications
Rated output voltage -48.8 VDC to -54 VDC -48.8 VDC to -54 VDC
Rated output current 99A 170A
Rated output power 4298 W 8310 W
Nominal power 4158 W at 208 VAC 7202 W at 208 VAC
Ambient Temperature Ambient Temperature Ambient Temperature Ambient Temperature
Range
Range Range Range (See NOTE NOTE NOTE NOTE)
Operating 50° to 95° F
(10° to 35° C) 50° to 95° F
(10° to 35° C)
Shipping -22° to 140° F
(-30° to 60° C) -22° to 140° F
(-30° to 60° C)
Relative humidity, Relative humidity, Relative humidity, Relative humidity,
non-condensing
non-condensing non-condensing non-condensing
(See NOTE NOTE NOTE NOTE)
Operating 20% to 80% 20% to 80%
Non-operating 5% to 95% 5% to 95%
Wet Bulb Wet Bulb Wet Bulb Wet Bulb
Temperature
Temperature Temperature Temperature
Operating 82.4° F (28° C) 82.4° F (28° C)
Non-operating 101.7° F (38.7° C) 101.7° F (38.7° C)
NOTE: NOTE: NOTE: NOTE: Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Upper
operating limit is 10,000 ft (3,048 m) or 70Kpa/10.1 psia. Upper non-operating limit is 30,000 ft (9,144 m) or
30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a maximum temperature of 113° F (45° C). Altitude
maximum for storage is 70 KPa.
QuickSpecs
ProLiant BL30p ProLiant BL30p ProLiant BL30p ProLiant BL30p
TechSpecs
DA - 11958 Canada — Version 2 — June 29, 2004 Page 34
