Operating and

Operating and
Performance

Performance

Performance
Specifications for

Specifications for

Specifications for
ProLiant BL p-Class RJ-45

ProLiant BL p-Class RJ-45

ProLiant BL p-Class RJ-45
Patch Panel

Patch Panel

Dimensions

Height

10.405 in (26.43 cm)

Width

1.535 in (3.899 cm)

Depth

27.697 in (70.35 cm)

Capability

IEEE 802.2, 802.3, 802.3u

Network Transfer Rate

10 Base-T (half-duplex)

10 Mbps

10 Base-T (full-duplex)

20 Mbps

100 Base-TX (half-duplex)

100 Mbps

100 Base-TX (full-duplex)

200 Mbps

1000 Base-TX (full-duplex)

1000 Mbps

Connector

Network

16 RJ-45 in the back

Cable Support

10 Base-TX

Categories 3, 4, or 5 UTP (2 or 4 pair);
up to 328 ft (100 m)

100 Base-TX

Category 5 UTP (2 pair); up to 328 ft (100 m)

1000 Base-TX

Category 5E (4 pair); up to 328 ft (100 m)

Power Requirements

200 mA at + 5V DC; 500 mA at -48V

Temperature Range

Operating

50° to 95° F (10° to 35° C)

Non-operating

-22° to 140° F (-30° to 60° C)

Relative Humidity

Relative Humidity
(non-condensing)

(non-condensing)

Operating

20% to 80%

Non-operating

5% to 95%

Wet Bulb Temperature

Operating

82.4° F (28° C)

Non-operating

101.7° F (38.7° C)

NOTE:

NOTE: Operating temperature has an altitude derating of 34° F (1° C) per 1,000 ft (304.8 m). No direct sunlight. Upper
operating limit is 10,000 ft (3,048 m) or 70Kpa/10.1 psia. Upper non-operating limit is 30,000 ft (9,144 m) or
30.3 KPa/4.4 psia. Storage maximum humidity of 95% is based on a maximum temperature of 113° F (45° C). Altitude
maximum for storage is 70 KPa.

Operating and

Operating and
Performance

Performance

Performance
Specifications for ProLiant

Specifications for ProLiant

Specifications for ProLiant
BL p-Class GbE

BL p-Class GbE

BL p-Class GbE
Interconnect Switch

Interconnect Switch

Dimensions

Height

10.405 in (26.43 cm)

Width

1.535 in (3.899 cm)

Depth

27.697 in (70.35 cm)

Weight

11.5 lb/5.2 kg per interconnect switch

Performance

9.6 Gbps external port bandwidth per server blade enclosure (full duplex)

Forwarding rate 0.15 million pps per 10/100 port, 1.5 million pps per gigabit port, (64-
byte packets)

Non-blocking, full-wire speed for all connections

Auto-MDI/MDIX, auto-negotiation and auto-sensing with full-duplex support

Forwarding Mode

Store and forward

MAC Addresses

8,191 per interconnect switch; MAC address based filtering and MAC address packet
priority configuring

Forwarding Table

Forwarding Table
Age Time

Age Time

Maximum age: 1 to 1,000,000 seconds; default: 300 seconds

Memory

32MB Main, 6MB flash and 16MB packet buffer per interconnect switch

Compliance

IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3z (F-GbE only), 802.1D, 802.1p, 802.3ac,
802.3ad (Static), and 802.1Q

SNMP v1 (RFC 1157) and RMON v1 (RFC 1757) groups 1, 2, 3, and 9

MIB-II (RFC 1213), Bridge MIB (RFC 1493), Interface Group MIB (RFC 2863), Ethernet MIB
(RFC 1643), 802.1Q Extended Bridge MIB (RFC 2674), Entity MIB (RFC 2037), SNMP Trap
Convention (RFC 1215), Bridge Trap (RFC 1493), Remote Monitoring Traps (RFC 1757),
and HP Enterprise Switch MIBs and Environmental Traps

IGMP v1 (RFC 1112), IGMP v2 (RFC 2236), SNTP (RFC 1361), Telnet (RFC 854), TFTP
client (RFC 783), BootP client, (RFC 2132), DHCP client, (RFC 2131) and ZModem,

QuickSpecs

ProLiant BL30p

TechSpecs

DA - 11958 Canada — Version 2 — June 29, 2004
