BL p-Class Server

BL p-Class Server
Blade Enclosures with

Blade Enclosures with

Blade Enclosures with
enhanced backplane

enhanced backplane

enhanced backplane
components

components

ProLiant BL p-Class Server Blade Enclosure (includes enhanced backplane components)

243564-B22

ProLiant BL p-Class Server Blade Enclosure with eight (8) ProLiant Essentials Rapid Deployment Pack
Licenses (includes enhanced backplane components)

NOTE:

NOTE: ProLiant BL p-Class server blade enclosures with enhanced backplane components are
required to support BL30p server blades.

281404-B22

ProLiant BL p-Class Server Blade Enclosure Upgrade Kit (option)

NOTE:

NOTE: Server Blade Enclosure Upgrade Kit (354100-B21) contains enhanced backplane
components and enables a field upgrade of a blade enclosure to support BL30p series blades and
provide a single, physical iLO port for the enclosure.

354100-B21

BL p-Class Interconnects

ProLiant BL p-Class Patch Panel 2 Kit with Fibre Channel pass-through (pair)

306465-B21

NOTE:

NOTE: Only one interconnect kit required per server blade enclosure.

ProLiant BL p-Class Patch Panel (pair)

230766-B21

NOTE:

NOTE: Only one interconnect kit required per server blade enclosure.

ProLiant BL p-Class C-GbE2 Interconnect Kit (with pair of GbE2 Interconnect Switches and two
QuadT2 Interconnect Modules)

283192-B21

NOTE:

NOTE: Only one interconnect kit required per server blade enclosure.

ProLiant BL p-Class F-GbE2 Interconnect Kit (with pair of GbE2 Interconnect Switches and two
QuadSX Interconnect Modules)

283193-B21

NOTE:

NOTE: Only one interconnect kit required per server blade enclosure.

ProLiant BL p-Class GbE2 Storage Connectivity Kit (with pair of OctalFC Interconnect Modules and
two Fibre Channel signal conditioning cards)

321745 -B21

NOTE:

NOTE: Required for BL30p Fibre Channel signal pass through when using the GbE2 Interconnect
Switch.
NOTE:

NOTE:

NOTE: Only one Storage Connectivity Kit required per each GbE2 Interconnect Kit.

ProLiant BL p-Class C-GbE Interconnect Kit (with pair of GbE Interconnect Switches and two QuadT
Interconnect Modules)

249655-B21

NOTE:

NOTE: Only one interconnect kit required per server blade enclosure.
NOTE:

NOTE:

NOTE: The GbE Interconnect Switch supports server NIC speeds to 100 Mbps. It is recommended
that a Patch Panel Kit or GbE2 Interconnect Switch Kit option be used if server NIC speeds to 1000
Mbps are required.
NOTE:

NOTE:

NOTE: To meet applicable radio frequency (RF) emission limits, the sidewall panels on the ends of
any individual rack or a series of coupled racks and the front and rear doors must be installed in any
racks containing more than one ProLiant BL p-Class GbE Interconnect Kit.

ProLiant BL p-Class F-GbE Interconnect Kit (with pair of GbE Interconnect Switches and two DualTSX
Interconnect Modules)

279720-B21

NOTE:

NOTE: Only one interconnect kit required per server blade enclosure.
NOTE:

NOTE:

NOTE: The GbE Interconnect Switch supports server NIC speeds to 100 Mbps. It is recommended
that a Patch Panel Kit option be used if server NIC speeds to 1000 Mbps are required.
NOTE:

NOTE:

QuickSpecs

ProLiant BL30p

Options

DA - 11958 Canada — Version 2 — June 29, 2004
