PARTS LIST
Key No. Part No. Description Qty.
1 1109403-0 DISPLAY ASSEMBLY 1
2 2268101-0 TILT MECH. ASSEMBLY 1
3 3848401-0 PLASTIC WASHER 2
4 401369 PLASTIC OVAL BAR COVER 3
5 HEX. HEAD SCREW NC 3/8-16*2 1/2 1
6 HEX. HEAD SCREW NC 3/8-16*1 3/4 1
7 2268001-0 LIFTER BOOM ASSEMBLY 1
8 2034701-0 MAIN BOARD TO CON. DIG CABLE 1
9 3809801-0 BEAM ASSEMBLY 1
10 PHIL.PAN HEAD SCREW NC6-32*1/4” 2
11 2138903-0 CON. DIG BOARD 1
12 SPACER WITH EX.THREAD STUD NC6*1/4” 2
13 SOCKET BUTTON HEAD CAP SCREW NC1/4-20*3/4” 2
14 SAFETY WASHER NC3/8” 2
15 401304 HEX. SOCKET HEAD SCREW NC3/8-16*1 1/2 2
16 3808401-0 STRETCHER HOOP 2
17 401338 STRETCHER 1
18 3835701-0 STRETCHER STORAGE TRAY 1
19 3833801-0 BAR ADAPTER 2
20 3808501-0 STRETCHER BAR 4
21 3816901-0 FORK JOINT 2
22 HEX. SOCKET HEAD SHOULDER SCREW (5/16) 3/8-1” 4
23 3816801-0 LOAD CELL ADAPTER 2
24 3828301-0 LOAD CELL CONNECTING BEAM 1
25 1304202-0 LOAD CELL 2
26 HEX. SOCKET HEAD CAP SCREW NC5/16-18*3/4” 4
27 NUT NC3/8” 2
28 401337 PLASTIC RHS50*50 COVER 2
29 400579 CABLE HOLDER P.G.-7 1
30 400066 SELF LOCK NUT NC3/8” 2
31 PHIL. PAN HEAD SCREW NC8*3/8” 6
32 3822701-0 CABLE COVER 1
33 400412 SELF LOCK NUT NC6 2
34 PHIL. PAN HEAD SCREW NC6-32*3/8” 2
35 3817001-0 ADATPER HOLDER 1
36 420988 ADAPTER 6VDC 120VAC 1
37 411220 KEYPAD 400LB 1
38 INDICATOR COVER 1
39 LCD WINDOW 1
40 LCD BOARD 1
41 WN1412 CROSS HEAD SCREW K22L6 4
42 DISPLAY TO EAGLE P.C.B CABLE 1
43 WN1412 CROSS HEAD SCREW K30L6 4
44 EAGLE BOARD 1
45 INDICATOR BASE 1
46 PHIL. PAN HEAD SCREW NC6-32*3/8” 6
47 MODEL LABEL 1
48 3245801-0 INPUT/OUTPUT PORTS LABEL 1
49 PHIL. PAN HEAD SCREW NC4-40*1/4” 1
50 3822801-0 BATTERY COVER 1
51 400152 RUBBER O RING 1
52 2033801-0 BATTERY HOLDER 1
--- 63855 PATIENT LIFT 1
