Page 2 September 1, 2008
4100-I ACT WOOD INSERT
250-7201E
R
IMpORTANT: THIS IS DATED INFORMATION. The most current information is located on the Quadra-Fire web site at www.
quadrafire.com. When ordering, supply serial and model numbers to ensure correct part.
Service parts and Accessories
Item
#
part Description
Alphabetical Order
SKU
1 Ashcatcher 435-0310
8 Baffle, Fiberboard 832-3520
9 Blanket, Ceramic 1/2” thick 832-3390
3 Blower Mount Base 435-0320
5 Blower Mount Clamp 435-0400
2 Blower Assembly, 180 cfm 832-3491
13 Blower Control Box with Switch (included wire harness) SRV7000-194
4 Blower Housing, Cast 435-0590
18 Brick Set 832-3500
Brick, Single (give dimensions of brick, see page 21) 832-0550
17 Brick, with holes (Set of 2) SRV435-0800
Brick, Uncut Set of 6 832-3040
Component Pack (includes Owner’s Manual, Touch-up Paint, Warranty Card, Door Handle, 2 Screws, Permanent Label “If Fireplace
Altered”).
435-5310
19 Door Assembly with Glass, Gold 435-5190
19 Door Assembly with Glass, Nickel 435-5300
19 Door Assembly with Glass, Gold 435-5340
19 Door Assembly with Glass, Nickel 435-5390
22 Door Handle, Fiber SRV433-1380
21 Door Frame, Cast 435-0050
Door Handle Assembly 832-3570
Door Handle Assembly
Door Handle Assembly
Latch Replacement Kit
SRV435-5510
Door Handle Arm (Metal) 435-1470
30 Door Latch Arm 435-0250
24 Hook, Door Latch 435-1190
23 Door Latch Bracket 435-1480
29 Door Latch Bracket 435-1370
10 Door Latch Box Assembly 435-5270
27 Glass Frame, Front 435-0960
25 Glass Frame, Side 435-0950
28 Glass Assembly, Front 435-5470
29 Glass Assembly, Side (1 piece) 435-5480
30 Hinge Pin, Gold 72171
30 Hinge Pin, Nickel 433-1590
12 Knob, Air Control 32284
7 Manifold Tubes, Set of 4 832-3530
Manifold Clips & Screws 832-0661
14 Outside Air Cover Plate 435-0290
19 Panel, Wire Access 435-0900
11 Snap Disc, 110 degrees 230-1220
