L300P Inverter
v
HIGH VOLTAGE: Be sure to ground the unit. Otherwise, there is a danger of electric shock and/or fire.
.............
2–13
HIGH VOLTAGE: Wiring work shall be carried out only by qualified personnel. Otherwise, there is a danger of electric shock and/or fire.
HIGH VOLTAGE: Implement wiring after checking that the power supply is OFF. Otherwise, you may incur electric shock and/or fire.
HIGH VOLTAGE: Do not connect wiring to an inverter or operate an inverter that is not mounted according the instructions given in this manual. Otherwise, there is a danger of electric shock and/or injury to personnel.
Wiring—Cautions for Electrical Practices
CAUTION: Be sure that the input voltage matches the inverter specifica-tions: • Three phase 200 to 240V 50/60Hz • Three phase 380 to 480V 50/60Hz
2–19
CAUTION: Be sure not to power a three-phase-only inverter with single phase power. Otherwise, there is the possibility of damage to the inverter and the danger of fire.
CAUTION: Be sure not to connect an AC power supply to the output termi-nals. Otherwise, there is the possibility of damage to the inverter and the danger of injury and/or fire.
Power Input
Power Output
R
S
T
T1
T2
T3
U
V
W
L1
L3
NOTE:
L1, L2, L3:
Three-phase 200 to 240V 50/60 HzThree-phase 380 to 480V 50/60 Hz
L2
