Step-by-Step Basic Installation
In
v
e
rt
er Moun
ting
and Install
a
tion
2–8
Step 4: Locate the applicable drawing on the following pages for your inverter.
Dimensions are given in millimeters (inches) format. The optional NEMA 1 wire entry conduit
box is shown for inverter models 37kW to 75kW (–370 to –550LFU2 / –370 to –750 HFU2,
U.S. models only).
4
Check Inverter
Dimensions
150(5.91)
130(5.12)
241(9.49) 255(10.04)
2 - 6(0.24)
130(5.12)
143(5.63)
7(0.28)
62(2.44)
140(5.51)
2 - f 6(0.24)
3 - f 20(0.79)
Model
L300P -015LFU2
-022LFU2
-037LFU2
-055LFU2
Air intake
Exhaust
-015HFU2
-022HFU2
-037HFU2
-055HFU2
210(8.27)
2 - f 7(0.28)
246(9.69)
189(7.44)
260(10.24)
7(0.28)
2 - 7(0.28)
189(7.44)
203(7.99)
82(3.23)
170(6.69)
3 - f 25(0.98)
Model
L300P
-075HFU2, HFE2
-110LFU2
Air intake
Exhaust
-075LFU2
-110HFU2, HFE2
-150LFU2
-150HFU2, HFE2
