L300P Inverter
Configur
ing Dr
iv
e
P
a
ra
met
e
rs
3–39
“B” Function
Run
Mode
Edit
Lo Hi
Defaults
Units
SRW Display
Func.
Code
Name
Description
–FE2
(CE)
–FU2
(UL)
–FR
(Jpn)
B080
[AM] terminal analog
meter adjustment
Adjust 8-bit gain to analog
meter connected to terminal
[AM], range is 0 to 255
✔ ✔ 180
180
180
—
>b080 AM-MONITOR
ADJUST 180
B081
[FM] terminal analog
meter adjustment
Adjust 8-bit gain to analog
meter connected to terminal
[FM], range is 0 to 255
✔ ✔
60
60
60
—
>b081 FM-MONITOR
ADJUST 060
B082
Start frequency adjust-
ment
Sets the starting frequency
for the inverter output, range
is 0.10 to 9.99 Hz
✘ ✔ 0.50 0.50 0.50
Hz
>b082 fmin
F 00.50Hz
B083
Carrier frequency
setting
Sets the PWM carrier (inter-
nal switching frequency).
Range is 0.5 to 8.0 kHz for
–015xxx to –750xxx models
and 0.5 to 12.0 kHz for
–900Hxx to 1320Hxx
✘ ✔
3.0
3.0
3.0
kHz
>b083 CARRIER
F 05.0kHz
B084
Initialization mode
(parameters or trip
history)
Select the type of initializa-
tion to occur, two option
codes:
00 Trip history clear
01 Parameter initialization
02 Trip history clear and
parameter initialization
✘ ✘
00
00
00
—
>b084 INITIAL
MODE TRP
B085
Country code for initial-
ization
Select default parameter
values for country on initial-
ization, four option codes:
00 Japan version
01 Europe version
02 US version
03 reserved (do not set)
✘ ✘
01
02
00
—
>b085 INITIAL
SELECT USA
B86
Frequency scaling
conversion factor
Specify a constant to scale
D007 to display in engineer-
ing units.
Range is 0.1 to 99.9
✔ ✔
1.0
1.0
1.0
—
>b086 F-CONV
Gain 001.0
B087
STOP key enable
Select whether the STOP
key on the keypad is enabled
(req. A002=01, 03, 04, or
05). Two option codes:
00 Enable
01 Disable
✘ ✔
00
00
00
—
>b087 STOP-SW
SELECT ON
