Parts - 2150
46 311879F
Fluid Section Parts List (Matrix Column 3)
Seat Parts List (Matrix Column 4)
* These parts are included in the Pump Repair Kit which
may be purchased separately. Refer to the Repair Kit Matrix on
page 42 to determine the correct kit for your pump.
▲ Replacement Danger and Warning labels, tags and cards
are available at no cost.
Ball Parts List (Matrix Column 5)
Diaphragm Parts List (Matrix Column 6)
* These parts are included in the Pump Repair Kit which
may be purchased separately. Refer to the Repair Kit Matrix on
page 42 to determine the correct kit for your pump.
Ref. Part No. Description Qty
101 277264 COVER, fluid; SST 2
102 277269 MANIFOLD, inlet; SST 1
103 277270 MANIFOLD, outlet; SST 1
106 15H513 CLAMP, sanitary, dia-
phragm 2
110 ▲ 188621 LABEL, warning 1
111 15G332 MUFFLER 1
113 510490 CLAMP, sanitary 4
Digit Ref. Part No. Description Qty
1 201 15H826 SEAT; 316 SST 4
202* 15H831 O-RING; PTFE 4
2 201 15H826 SEAT; 316 SST 4
202* 15H829 O-RING; EPDM 4
Digit Ref. Part No. Description Qty
1 301* 112359 BALL; PTFE 4
2 301* 112361 BALL; Santoprene® 4
3 301* 15H834 BALL; neoprene/SST
core 4
Digit Ref. Part No. Description Qty
1 401* DIAPHRAGM; backer;
EPDM 2
402* 112181 PACKING; u-cup;
nitrile 2
403* 15K313 DIAPHRAGM; PTFE 2
104 189298 PLATE, air side;
aluminum 2
105 189299 PLATE, fluid side; SST 2
107 189410 BOLT; M12 x 1.75;
55 mm (2.16 in.); SST 2
108* 104319 O-RING; PTFE 2
2 402* 112181 PACKING; u-cup;
nitrile 2
403* 189296 DIAPHRAGM;
Santoprene® 2
104 189298 PLATE, air side;
aluminum 2
105 189299 PLATE, fluid side; SST 2
107 189410 BOLT; M12 x 1.75;
55 mm (2.16 in.); SST 2
108* 104319 O-RING; PTFE 2
3 289226 Kit, heavy-duty diaphragm, PTFE;
includes 403 and 104
402* 112181 PACKING; u-cup;
nitrile 2
403* 253628 DIAPHRAGM;
Heavy-Duty; PTFE;
includes two dia-
phragms and two
packings (402) 1
104 15H811 PLATE, air side;
aluminum 2
