Pump Matrix - 1590

311879F

Pump Matrix - 1590

1590 FDA-Compliant Stainless Steel Sanitary Pumps

Your Model No. is marked on the pump’s serial plate. To
determine the Model No. of your pump from the follow-
ing matrix, select the six digits which describe your
pump, working from left to right. The first three digits are
always FD2, designating 1590 SST FDA compliant dia-
phragm pumps. The remaining three digits define the
materials of construction. For example, a 1590 FDA

pump with a stainless steel motor, stainless steel fluid
section, stainless steel seats, PTFE o-rings, PTFE balls,

and PTFE diaphragms is Model No.

FD2111.

To order

replacement parts, refer to the part lists on pages 37 -38.

The digits in the matrix do not correspond to the refer-
ence numbers in the parts drawings and parts lists.

Available Configurations

• FD2111

• FD2122

• FD2211

• FD2222

• FD2113

• FD2213

• FD2132

• FD2232

FDA-Compliant
Diaphragm
Pump

1590 Stainless
Steel Air Motor

Stainless Steel
Fluid Section

Seats and
O-rings

Balls

Diaphragms

FD2 - All 1590 Stainless Steel FDA-Compliant Pumps

1 (316 SST with

PTFE o-rings)

1 (PTFE)

2 (316 SST with

EPDM o-rings)

2 (Santoprene®)

3 (Neoprene

with SST core)

3 (PTFE

Heavy-Duty)
