Pump Matrix - 1040

311879F

Pump Matrix - 1040

1040 FDA-Compliant Stainless Steel Sanitary Pumps

Your Model No. is marked on the pump’s serial plate. To
determine the Model No. of your pump from the follow-
ing matrix, select the six digits which describe your
pump, working from left to right. The first three digits are
always FD1, designating 1040 SST FDA-compliant
pumps. The remaining three digits define the materials
of construction. For example, a 1040 FDA pump with

PTFE o-rings, stainless steel seats, PTFE balls, and

PTFE diaphragms is Model

FD1111.

To order replace-

ment parts, refer to the part lists on pages 29-30.

The digits in the matrix do not correspond to the refer-
ence numbers in the parts drawings and parts lists.

Available Configurations

• FD1111

• FD1122

• FD1211

• FD1222

• FD1113

• FD1213

• FD1132

• FD1232

FDA- Compliant
Diaphragm
Pump

1040 Stainless
Steel Air Motor

Stainless Steel
Fluid Section

Seats and
O-rings

Balls

Diaphragms

FD1 - All 1040 Stainless Steel FDA-Compliant pumps.

1 (316 SST with

PTFE o-rings)

1 (PTFE)

2 (316 SST with

EPDM o-rings)

2 (Santoprene®)

3 (Neoprene

with SST core)

3 (PTFE

Heavy-Duty)
