Parts - 1040
30
311879F
Fluid Section Parts List (Matrix Column 3)
*
These parts are included in the Pump Repair Kit which
may be purchased separately. Refer to the Repair Kit Matrix on
page 27 to determine the correct kit for your pump.
▲
Replacement Danger and Warning labels, tags, and cards
are available at no cost.
Seat Parts List (Matrix Column 4)
Ball Parts List (Matrix Column 5)
Diaphragm Parts List (Matrix Column 6)
*
These parts are included in the Pump Repair Kit which
may be purchased separately. Refer to the Repair Kit Matrix on
page 27 to determine the correct kit for your pump.
Ref. Part
No.
Description
Qty
101
277262
COVER, fluid; SST
2
102
277265
MANIFOLD, inlet; SST
1
103
277266
MANIFOLD, outlet; SST
1
106
15G698
CLAMP, diaphragm
2
110
▲
188621
LABEL, warning
1
111
15G332
MUFFLER
1
113
620223
CLAMPS, sanitary
4
Digit
Ref. Part
No.
Description
Qty
1
201
15H824
SEAT; 316 SST
4
202*
15J280
O-RING; PTFE
4
2
201
15H824
SEAT; 316 SST
4
202*
15H827
O-RING; EPDM
4
Digit
Ref. Part
No.
Description
Qty
1
301*
112088
BALL; PTFE
4
2
301*
112092
BALL; Santoprene®
4
3
301*
15H832
BALL; neoprene/SST
core
4
Digit
Ref. Part
No.
Description
Qty
1
401*
DIAPHRAGM; backer;
EPDM
2
402*
112181
PACKING; u-cup; nitrile
2
403*
188605
DIAPHRAGM; PTFE
2
104
188607
PLATE, air side;
aluminum
2
105
15C039
PLATE, fluid side; SST
2
107
189044
BOLT; M12 x 1.75;
35 mm (1.38 in.); SST
2
108*
104319
O-RING; PTFE
2
2
402*
112181
PACKING; u-cup; nitrile
2
403*
188857
DIAPHRAGM; Santo-
prene
2
104
188607
PLATE, air side;
aluminum
2
105
15C039
PLATE, fluid side; SST
2
107
189044
BOLT; M12 x 1.75;
35 mm (1.38 in.); SST
2
108*
104319
O-RING; PTFE
2
3
289224 Kit, heavy-duty diaphragm, PTFE; includes
403 and 104
402*
112181
PACKING; u-cup; nitrile
2
403*
253626
DIAPHRAGM;
Heavy-Duty; PTFE;
includes two dia-
phragms and two pack-
ings (402)
1
104
15H809
PLATE, air side;
aluminum
2
