38
ENGLISH
With Composite Input and S-video Input (AV1 and AV2 input)
Signal mode
No.
Signal name Resolution Vertical frequency (Hz)
Horizontal
frequency (kHz)
Remarks
1 NTSC-M 525 59.94 15.73
2 PAL-N 625 50 15.63
With Component YPb, Pr input (AV3 and AV4 input)
Signal mode
No.
Signal name Resolution Vertical frequency (Hz)
Horizontal
frequency (kHz)
Remarks
1 480i 480 59.94 15.73
2 480p 480 59.94 31.47
3 1080i/60 1080 60 33.75
4 720p/60 720 60 45.00
x The monitor differentiates the signal modes according to the horizontal and vertical frequencies and the horizontal and vertical sync signal polarities. Note
that different signals having all these elements alike may be handled as the same signal.
