Hitachi CMP4221 - Manual (Page 11)

11
ENGLISH
Remote Control
l
Handling the Remote Control
Use the remote control within about 5m from the front of the unit’s
remote-control sensor and within 30 degrees on both sides.
1. Open the battery cover.
Slide back and remove the battery
cover in the direction of the arrow.
2. Load batteries.
Load two Size AAA batteries included observing the Polarities .
3. Close the battery cover.
Replace the battery cover in the direction of the arrow and snap it back
into place.
With in 30
degrees
With in 30
degrees
About 3m About 3m
About 5m
CAUTION
z Do not use new and old batteries together. The batteries could explode or
leak, resulting in fires, physical injury, or stains.
z When loading batteries, observe their correct polarities as marked on the
product. If loaded in the wrong direction, the batteries could explode or
leak, resulting in fires, physical injury, or stains.
ATTENTION
z Do not drop or impact the remote control..
z Do not splash the remote control with water or put it on a wet object.
z Before leaving the remote control out of use for an extended period of
time, remove the batteries from it.
z If the remote control begins to lack responsiveness, replace the
batteries.
z Strong light, such as direct sunlight, shining on the photoreceptor of
the remote control can cause operational failure.Position this unit to
avoid direct contact with such light.
POWER ON button 16
OK button 19
AUTO button 18
PIP button 25
16 POWER OFF button
16 POWER ON/OFF
b tt
17 AV1 button
17 VOLUME UP/DOWN buttons
17 AV4 button
19 RETURN button
18 RECALL button
17 SIZE button
HDMI button 17
AV2 button 17
AV3 button 17
19 SELECT/OK buttons
RGB button 17
MENU button 19
17 MUTE button
Loading Batteries Handing the Remote Control
