37
ENGLISH
PRODUCT SPECIFICATIONS (continued)
Recommended Signal List
With Analog RGB signal input (RGB input)
Signal mode
No.
Signal name Resolution
Vertical frequency
(Hz)
Horizontal frequency
(kHz)
Dot clock frequency
(MHz)
Remark
1 640 x 400 70.08 31.47 25.18
2
VGA
640 x 480 59.94 31.47 25.18
3 W-VGA 864 x 480 59.94 31.47 34.24 WVGA Type: On
4 640 x 480 72.81 37.86 31.50
5 640 x 480 75.00 37.50 31.50
6 640 x 480 85.01 43.27 36.00
7 800 x 600 56.25 35.16 36.00
8 800 x 600 60.32 37.88 40.00
9 800 x 600 72.19 48.08 50.00
10 800 x 600 75.00 46.88 49.50
11 800 x 600 85.06 53.67 56.25
12 1024 x 768 60.00 48.36 65.00
13 1024 x 768 70.07 56.48 75.00
14 1024 x 768 75.03 60.02 78.75
15 1024 x 768 85.00 68.68 94.50
16 1152 x 864 75.00 67.05 108.00
17 1280 x 1024 60.02 63.98 108.00
18 1280 x 1024 75.03 79.98 135.00
19 1280 x 1024 85.02 91.15 157.50
20
VESA
1600 x 1200 60.00 75.00 162.00
21 640 x 480 66.67 35.00 30.24
22 832 x 624 74.55 49.72 57.28
23 1024 x 768 74.93 60.24 80.00
24
Macintosh
1152 x 870 75.06 68.68 100.00
25 1280 x 768 59.833 47.986 81.00
26
W-XGA
1280 x 768 69.997 56.137 94.76
x The type of video board or connecting cable used, may not allow for correct display adjustment of Horizontal Position, Vertical Position, Horizontal Clock
and Clock Phase.
x The monitor may fail to display an animation image correctly when a signal having a vertical frequency of 85Hz or higher is input to it.
x The monitor differentiates the signal modes according to the horizontal and vertical frequencies and the horizontal and vertical sync signal polarities. Note
that different signals having all these elements alike may be handled as the same signal.
x Displaying images with more than 512 lines of vertical resolution at Full display (compressed display) can result in the interpolation of stripes.
With HDMI input
Signal mode
No.
Signal name Resolution Vertical frequency (Hz)
Horizontal
frequency (kHz)
Dot clock frequency
(MHz)
1 640 x 480 70.08 31.47 25.18
2
VGA
640 x 480 59.94 31.47 25.18
3 W-VGA 864 x 480 59.94 31.47 34.24
4 640 x 480 72.81 47.86 31.50
5 640 x 480 75.00 37.50 31.50
6 640 x 480 85.01 43.27 36.00
7 800 x 600 56.25 35.16 36.00
8 800 x 600 60.32 37.88 40.00
9 800 x 600 72.19 48.08 50.00
10 800 x 600 75.00 46.88 49.50
11 800 x 600 85.06 53.67 56.25
12 1024x 768 60.00 48.36 65.00
13 1024x 768 70.07 56.48 75.00
14
VESA
1024x 768 75.03 60.02 78.75
15 480i 720 x 480 59.94 15.73 27.00
16 480p 720 x 480 59.94 31.47 27.00
17 1080i/60 1920 x 1080 60 33.75 74.25
18 720p/60 1280 x 720 60 45.00 74.25
x The monitor differentiates the signal modes according to the horizontal and vertical frequencies and the horizontal and vertical sync signal polarities. Note
that different signals having all these elements alike may be handled as the same signal.
x Displaying images with more than 512 lines of vertical resolution at Full display (compressed display)can result in the interpolation of stripes
x Make sure that the signal of the equipment to be connected is compatible with the specifications of this list.
