32 HP High-Definition LCD TV Service Manual
This chapter contains the service parts lists of each model.
Parts List by Model
To see the pictures of the replaceable parts, go to the “Replacement Parts List Reference Picture” section.
Model LT3200
Number Part Description OEM Part Numbers HP Part Number
1 Stand base 60.3YI02.001 452084-001
2 Stand neck assy
Stand neck
Repair screw kit
42.3YI02.001
6K.3YISC.003 455587-001
3 Power supply assy - For 3x models -230W
Power supply - 3x model
System board to power supply cable
56.04230.Q01
50.3YJ02.001 455591-001
4 Main Board assy
Main board
System board to power supply cable
91.3YW10.001G
50.3YJ02.001 455593-001
5 Back cover - bucket 60.3YI07.001 452092-001
6 Keypad - Infrared assy
Keypad buttons
Keypad PCA board
Infrared board
System board to keypad/IR cable
60.3YJ03.001
91.3YK10.003G
91.3YK10.002G
50.3YJ03.001 455604-001
7 Internal support wall mount 33.3YI06.001 452097-001
8 Mesh bracket board cover 34.3YI01.001 452098-001
9 Speakers (L and R and wire connectors) 23.40276.001 452108-001
10 Front bezel including speaker cover 60.3YI01.001 452114-001
11 I/O bracket with AC inlet 90.3YI28.007G 452126-001
12 Inverter board
Inverter board - Master
Inverter cable
27-D010279
50.3YI02.001 455596-001
13 Control board
Control board
LVDS cable
35-D013932
50.3YI01.001 455600-001
-- Power cord 8121-0740 --
-- Remote control 5188-6301 / 90.3YI26.001 452113-001
-- Cable clamp 38.05031.001 452127-001
-- Repair screw kit 34.37P06.001 (2)
86.00G29.668 (4)
86.1A334.6R0 (4)
86.1A336.6R0 (10)
86.1H524.8R0 (4)
86.RA324.100 (2)
86.VA314.6R0 (4)
86.VA326.100 (4)
86.9A338.150 (8)
86.TA526.100 (4) 452128-001
-- VGA cord -- 453143-001
-- Whole unit – head only -- 451704-001
