Connecting to a Windows NT Server 4.0
Windows 95 SR2
3 Insert a DOS bootable diskette and power on the machine.
4 After booting, insert the 3COM drivers disk 1, “Etherlink 3C905 Ethernet
Drivers Ver. 2.1.” and execute “A:\3C90XCFG.EXE.”
5 Select “Configure NIC” and verify the resource settings listed above under
the heading “Device Configuration.”
6 If changes are required, save those changes and exit.
7 Remove the 3Com software driver diskette and reboot the machine.
8 When Windows 95 restarts, a message will appear to indicate that new
hardware has been found.
9 Insert disk 1 of 3Com Etherlink 3C905 software ver 2.1
10 Click on “Next” to begin hardware wizard on the “Update Device Driver
Wizard” dialog message.
11 Click on “Other Locations” in the “Update Device Driver Location” dialog
box, and set path to “A:\” then click “OK.” (If you have an HP preloaded
HDD, set the path statement to “C:\MASTERS\LANDRV\3C905\DISK1\”).
12 “3Com EtherLink XL TPO 10Mb Ethernet Adapter” should now be listed,
click on “Finish”.
13 Insert Disk 2 of 2 of the 3Com drivers disks and click “OK” in the “Insert
Disk” dialog box.
14 In “Copying Files…” dialog box , set path to “A:\” (If you have an HP pre-
loaded HDD, set the path statement to
“C:\MASTERS\LANDRV\3C905\DISK2\”).
15 Click “OK” to continue installation.
16 Click “OK” to the “Network” dialog box , to provide computer / work group
names.
17 Specify your Computer Name, Workgroup, and Computer Description. (If
you do not have the required information, contact your network
administrator.)
18 Click on the “Configuration” folder in the “Network” dialog box.
19 Click on “Add” and then protocol from “Select Network Component Type”
and click on “Add”.
20 Pick “Microsoft” from the “Manufacturers:” and “TCP/IP” , and then click
“OK”.
