Operating

1P SKU

2P SKU

LWAd

4.1 B

4.7 B

LpAm

22 dBA

28 dBA

Emissions Classification

Emissions Classification
(EMC)

(EMC)

FCC Rating

Class A

Normative Standards

CISPR 22; EN55022; EN55024; FCC CFR 47,
Pt 15; ICES-003; CNS13438; GB9254;
K22;K24; EN 61000-3-2; EN 61000-3-3; EN
60950-1; IEC 60950-1

NOTE:

NOTE: Product conformance to cited product specifications is based on
sample (type) testing, evaluation, or assessment. This product or family of
products is eligible to bear the appropriate compliance logos and
statements.
NOTE:

NOTE:

NOTE: The Listed sound levels apply to standard shipping configurations.
Additional options may result in increased sound levels.

Smart Array P410i

Smart Array P410i
Controller

Controller

Dimensions

Dimensions (not including
bracket)

Low Profile PCIe Form Factor
7.5 in x 9.5 in x 2.25 in (19.05 cm x 24.13 cm x 5.72 cm)

Disk Drive and Enclosure

Disk Drive and Enclosure
Interface - transfer rate

Interface - transfer rate

6Gb/s SAS (Serial Attached SCSI)
3Gb/s SATA (Serial ATA)

SAS Connectors

2 internal (Mini-SAS) x8 wide port connectors

Cache Memory Speed

DDR2-533MHz with 40 or 72-bit wide bus provides up to 4.2 GB/s
maximum bandwidth.

Server Interface

x8 2.5G PCIe 2.0 provides 2GB/s maximum bandwidth

SAS Speed

x8 3G SAS provides 2.4GB/s maximum bandwidth

Cache Memory

40-bit 256MB ECC protected cache (72-bit 512MB BBWC module
upgrades available); transportable with battery-backed upgrade

Logical Drives Supported

Logical Drives Supported Up to 64 logical drives

Maximum Logical Drive

Maximum Logical Drive
Capacity

Capacity

Greater than 2TB

Host Memory Addressing

Host Memory Addressing 64-bit, supporting greater than 4GB server memory space
RAID Support

RAID Support

RAID 6, 6+0 (Advanced Data Guarding)

NOTE:

NOTE: RAID 6, 6+0 can be enabled with either

Minimum of 256 MB cache, Battery kit and Smart Array Advanced
Pack License key option upgrades
Minimum of 512 MB BBWC and Smart Array Advanced Pack License
key option upgrades

RAID 5, 5+0 (Distributed Data Guarding)

NOTE:

NOTE: The 256 MB is required to enable RAID 5, 5+0 support of the Smart
Array P410i

RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)

Upgradeable Firmware

Upgradeable Firmware with Recovery ROM feature

QuickSpecs

HP ProLiant DL380 Generation 6 (G6)

Technical Specifications

DA - 13234 North America — Version 25 — December 18, 2009
