Standard memory plus optional memory (1 CPU model) Standard memory plus optional memory (1 CPU model) Standard memory plus optional memory (1 CPU model) Standard memory plus optional memory (1 CPU model)
54GB, consisting of three (3) 2GB RDIMMs plus six (6) 8GB RDIMMs
3x 2GB dual-rank PC3-10600 RDIMMs
6x 8GB dual-rank PC3-8500 RDIMMs
CPU1 CPU1 CPU1 CPU1 CPU2 CPU2 CPU2 CPU2
slot # population order slot # population order
Chnl 1 1 G; 8GB DIMM 1 G; empty Chnl 1
2 D; 8GB DIMM 2 D; empty
3 A; 2GB DIMM 3 A; empty
Chnl 2 4 H; 8GB DIMM 4 H; empty Chnl 2
5 E; 8GB DIMM 5 E; empty
6 B; 2GB DIMM 6 B; empty
Chnl 3 7 I; 8GB DIMM 7 I; empty Chnl 3
8 F; 8GB DIMM 8 F; empty
9 C; 2GB DIMM 9 C; empty
Standard memory replaced with optional memory (1 CPU model) Standard memory replaced with optional memory (1 CPU model) Standard memory replaced with optional memory (1 CPU model) Standard memory replaced with optional memory (1 CPU model)
RDIMM maximum configuration (1 CPU model)
RDIMM maximum configuration (1 CPU model) RDIMM maximum configuration (1 CPU model) RDIMM maximum configuration (1 CPU model)
96GB, consisting of six (6) 16GB quad-rank PC3-8500 RDIMMs
CPU1 CPU1 CPU1 CPU1 CPU2 CPU2 CPU2 CPU2
slot # population order slot # population order
Chnl 1 1 G; empty 1 G; empty Chnl 1
2 D; 16GB DIMM 2 D; empty
3 A; 16GB DIMM 3 A; empty
Chnl 2
4
H; empty
4 H; empty
Chnl 2
5 E; 16GB DIMM 5 E; empty
6 B; 16GB DIMM 6 B; empty
Chnl 3 7 I; empty 7 I; empty Chnl 3
8 F; 16GB DIMM 8 F; empty
9 C; 16GB DIMM 9 C; empty
UDIMM maximum configuration (1 CPU model) UDIMM maximum configuration (1 CPU model) UDIMM maximum configuration (1 CPU model) UDIMM maximum configuration (1 CPU model)
12GB, consisting of six (6) 2GB dual-rank PC3-10600 UDIMMs
QuickSpecs
HP ProLiant DL380 Generation 6 (G6) HP ProLiant DL380 Generation 6 (G6) HP ProLiant DL380 Generation 6 (G6) HP ProLiant DL380 Generation 6 (G6)
Memory
DA - 13234 North America — Version 25 — December 18, 2009 Page 40
