Page 25
24
Connecting to a Video Camera
The instructions presented here are a general guide to connecting
the TV to a camcorder or other type of digital camera. Actual connec-
tions may vary according to the make and model of the device. Refer
to the user’s manual included with the camcorder or camera for more
detailed instructions.
Note
The cables are color-coded (black, red, white, yellow). Connect each color-
coded cable to the appropriate connector on your device.
WB
S
B
R
W
Y
SPEAKER
AV
SPEAKER
AV
4-IN-1 cable
S-Video
connector
AV connectors
4-in-1 Jack
