QuickSpecs
hp StorageWorks
modular SAN array 1000
specific for Tru64 UNIX and OpenVMS only
DA-11621
Canada — Version 2 — April 15, 2003
16
Technical Specifications
M
O D U L A R
S A N A
R R A Y
1 0 0 0 C
O N T R O L L E R
User Interface
Controller Display with Status Indicators (2) and Push Buttons (4)
Status Indicators on front of Controller (16)
Electrical Interface
LVD (Low Voltage Differential)
Protocol Support
Wide Ultra3 SCSI (160 MB/s per channel)
SCSI Ports
4-channel: 2 external/2 Internal
Drives Supported
Up to 42 drives
Maximum Capacity
6.0 TB (42 drives x 146 GB)
Logical Drives
Up to 32 logical drives
RAID Support
RAID ADG (Advanced Data Guarding)
RAID 5 (Distributed Data Guarding)
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)
Cache Memory
Up to 512 MB Read/Write (256-MB modules). Added cache size must match original and if a second controller is
employed, it too must have equally configured cache.
ECC protection, battery-backed, and removable
Standard, starting November 19, 2002: 256 MB cache memory (single module)
Cache Batteries
Up to three days of redundant battery life, removable for easy replacement
Upgradeable Firmware
2 MB flashable ROM
Disk Drive and Enclosure
Protocol Support
HP Ultra 320, Ultra3, and Ultra2 SCSI 1-inch Universal drives
Packaging
Dimensions (L x W x D)
17 x 12.5 x 7.75 in/43.2 x 31.75 x 19.7 cm
Weight
Gross 6 lb/2.72 kg
M
O D U L A R
S A N A
R R A Y
F
I B R E
C
H A N N E L
I / O M
O D U L E
Connector Type
LC
Number of Fibre Channel Ports One 2 Gb Fibre Channel Port using removable Small-Form-Factor-Pluggable Transceiver (SFP)
Bandwidth
200 MB/s
Operation Modes
Fibre Channel Class 2 and 3 connectionless service
Protocols Supported
Fibre Channel
Packaging
Dimensions (L x W x D)
17 x 12.5 x 7.75 in/43.2 x 31.75 x 19.7 cm
Weight
Gross 6 lb/2.72 kg
F C A 2 3 5 4 H
O S T
A
D A P T E R
Connector Type
LC
Protocol
SCSI, IP
Data Transfer Method
64-bit/66 MHz PCI
Maximum Transfer Rate
200 MB/s
Packaging
Dimensions (L x W x D)
11 x 8.5 x 3 in/27.9 x 21.6 x 7.6 cm
Weight
Gross 1 lb/0.45 kg
