QuickSpecs

hp StorageWorks

modular SAN array 1000

specific for Tru64 UNIX and OpenVMS only

DA-11621

Canada — Version 2 — April 15, 2003

Configuration Information

T E P

3 – C

H O O S E

E D U N D A N T M S A

1 0 0 0 S

Y S T E M

P T I O N S

Redundant Configuration

msa1000 Controller

218231-B22

NOTE: Redundant configurations require two Host Adapters per server, an additional

controller for each server. Mixing of the msa Fibre Channel I/O Modular and the

msa Hub 2/3 is not supported. When configuring the msa1000 for redundant

controllers use either two msa Fibre Channel I/O Modules, two msa SAN switch

2/8s, or two msa Hub 2/3s.

msa Fibre Channel I/O Module (Includes 2 Gb SFP transceiver)

218960-B21

msa Hub 2/3 (integrated) (Includes two 2Gb SFP transceivers)

286763-B21

msa SAN Switch 2/8 (integrated) (Includes four 2Gb SFP transceivers)

288247-B21
