QuickSpecs
hp StorageWorks
modular SAN array 1000
specific for Tru64 UNIX and OpenVMS only
DA-11621
Canada — Version 2 — April 15, 2003
12
Configuration Information
S
T E P
4 – C
H O O S E
S
U P P O R T E D
O
P T I O N S
F
O R
2 G
B O R
1 G
B
I
N F R A S T R U C T U R E (continued)
2 Gb Fibre Channel HBAs
FCA2354 Host Adapter (Tru64 UNIX, OpenVMS)
261329-B21
Fibre Channel Cables for 2 Gb
Infrastructure
Use 2 Gb Fibre Channel cables when connecting the msa Fibre Channel I/O Module or
the msa Fabric Switch 6 to FCA2101 HBA(s)
2 m LC-LC Multi-Mode Fibre Channel Cable
221692-B21
5 m LC-LC Multi-Mode Fibre Channel Cable
221692-B22
15 m LC-LC Multi-Mode Fibre Channel Cable
221692-B23
30 m LC-LC Multi-Mode Fibre Channel Cable
221692-B26
50 m LC-LC Multi-Mode Fibre Channel Cable
221692-B27
Fibre Channel Cables for 1 Gb
Fabric Switches and Hub
Use 1 Gb Fibre Channel cables when connecting the msa Fibre Channel I/O Module
and FCA2354 HBA(s) to 1 Gb fabric switches or hubs.
2 m LC-SC Multi-Mode Fibre Channel Cable
221691-B21
5 m LC-SC Multi-Mode Fibre Channel Cable
221691-B22
15 m LC-SC Multi-Mode Fibre Channel Cable
221691-B23
30 m LC-SC Multi-Mode Fibre Channel Cable
221691-B26
50 m LC-SC Multi-Mode Fibre Channel Cable
221691-B27
S
T E P
5 – C
H O O S E
H
A R D
D
R I V E S
& S
T O R A G E
W
O R K S
E
N C L O S U R E S
Hard Drives
36.4 GB Pluggable Ultra320 Universal Hard Drive, 10,000 rpm (1
″
)
286713-B22
72.8 GB Pluggable Ultra320 Universal Hard Drive, 10,000 rpm (1
″
)
286714-B22
146.8 GB Pluggable Ultra320 Universal Hard Drive, 10,000 rpm (1
″
)
286716-B22
18.2 GB Pluggable Ultra320 Universal Hard Drive, 15,000 rpm (1
″
)
286775-B22
36.4 GB Pluggable Ultra320 Universal Hard Drive, 15,000 rpm (1
″
)
286776-B22
72.8 GB Pluggable Ultra320 Universal Hard Drive, 15,000 rpm (1
″
)
286778-B22
*NOTE: All Ultra320 Universal Hard Drives are backward compatible to U2 or U3
speeds.
NOTE: For complete compatibility information, refer to the HP SCSI Hard Drive
Compatibility table located at:
NOTE: This Web site is available in English only.
