2.2.9 Connecting HDMI
HDMI (High Definition Multimedia Interface) with HDCP (High Definition
Copy Protection) assures that the best video signal is always sent from
source (HDTV signal, DVD player) to the TV.
Refer to the following illustration to connect an HDMI device to the TV.
Note:
When the HDMI cable is connected, connecting the audio cable is not
necessary. However, it is necessary to do so if the HDMI-DVI-D adapter
cable is connected.
R
L
Audio cable
HDMI cable
DVD player
HDMI
output
