HP ze2000 - Manual (Page 105)

5–12 Maintenance and Service Guide
Removal and Replacement Procedures
3. Remove the black PM2.0×6.0 screw 1 that secures the
optical drive to the notebook.
✎
The Compaq Presario M2000 optical drive is secured by
one black PM2.0×7.0 screw.
4. Insert a thin tool, such as a paper clip, into the media tray
release hole 2. (The optical drive media tray releases from
the optical drive.)
5. Use the media tray frame to slide the optical drive to
the right 3.
6. Remove the optical drive.
Removing the Optical Drive
Reverse the above procedure to install an optical drive.
