Removal and Replacement Procedures

Maintenance and Service Guide

5–7

5. Remove the hard drive by following these steps:

a. Position the notebook with the rear panel toward you.

b. Loosen the 2 black PM2.0×5.0 screws 1 that secure the

hard drive cover to the notebook.

c. Lift the right side of the cover and swing it to the left 2.

d. Remove the hard drive cover.

✎

The hard drive cover is included in the Miscellaneous
Plastics Kits, spare part numbers 382400-001 (for use on
HP Pavilion ze2000 models) and 382401-001 (for use on
Compaq Presario M2000 models).

Removing the Hard Drive Cover

Hard Drive Spare Part Number Information

80-GB (4200-rpm; includes frame and connector)
60-GB (4200-rpm; includes frame and connector)
40-GB (4200-rpm; includes frame and connector)

381398-001
381397-001
381396-001
