NOTE: This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid
configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales
representative for information on CTO product offerings and requirements.
NOTE: HP does not allow factory integration of options into standard models listed above. Configure-to-order servers must
start with a CTO Chassis.
NOTE: FIO indicates that this option only available as a Factory Installable Option.
Step 1: Base Configuration (choose one of the following configurable models)
HP Models DL320G6 CTO (Configure to Order) Chassis 505768-B21
Includes:
Embedded NC326i Dual Port Gigabit Server Adapter
1 full length PCI Express x16 slot and 1 half length low profile PCI Express x4
slot
Integrated Lights-Out 2 (ProLiant Onboard Administrator powered by Integrated
Lights-Out 2) embedded (shared NIC functionality standard)
HP Smart Array B110i SATA RAID Controller (RAID 0/1/0+1)
Rack (1U) form factor, (1.70 in/4.32 cm)
Fixed, mounting rails
Step 2: Choose Required Options (only one of the following from each list unless
otherwise noted)
HP Processors Six-Core Processors
Intel® Xeon® Processor X5650 (2.66 GHz, 12MB L3 Cache, 95W, DDR3-1333,
HT, Turbo 2/2/2/2/3/3) FIO 600743-L21
Quad-Core Processors
Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800),
FIO 512058-L21
Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800),
FIO 512059-L21
Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066,
HT, Turbo 1/1/2/2), FIO 512060-L21
Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3 1066,
HT, Turbo 1/1/2/2), FIO 512061-L21
Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066,
HT, Turbo 1/1/2/2), FIO 512062-L21
Intel® Xeon® Processor E5620 (2.40 GHz, 12MB L3 Cache, 80W, DDR3-1066,
HT, Turbo 1/1/2/2) FIO 600739-L21
Intel® Xeon® Processor E5630 (2.53 GHz, 12MB L3 Cache, 80W, DDR3-1066,
HT, Turbo 1/1/2/2) FIO 600740-L21
Intel® Xeon® Processor E5640 (2.66 GHz, 12MB L3 Cache, 80W, DDR3-1066,
HT, Turbo 1/1/2/2) FIO 602252-L21
Intel® Xeon® Processor L5506 (2.13 GHz, 4MB L3 Cache, 60W, DDR3-800),
FIO 512063-L21
Intel® Xeon® Processor L5609 (1.86 GHz, 12MB Cache, 40W, DDR3-1066) FIO 600741-L21
Intel® Xeon® Processor L5520 (2.26 GHz, 8MB L3 Cache, 60W, DDR3-1066,
HT, Turbo 1/1/2/2), FIO 512064-L21
Intel® Xeon® Processor L5630 (2.13 GHz, 12MB L3 Cache, 40W, DDR3-1066,
HT, Turbo 1/1/2/2/) FIO 600742-L21
QuickSpecs
HP ProLiant DL320 Generation 6
Configuration Information - Factory Integrated Models
DA - 13344 Worldwide QuickSpecs — Version 19 — 4.22.2010 Page 15
