background image

QuickSpecs

hp ProLiant ML570

Generation 2 (G2)

DA-11421

World Wide — Version 2 — November 19, 2002

6

Standard Features

R a c k A i r f l ow Requirements

Rack 9000 and 10000 series Cabinets
The increasing power of high-performance processor technology requires increased cooling efficiency for

rack-mounted servers. The Compaq 9000 Series Rack and the new 10000 Series Racks provides enhanced

airflow for maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.

Rack 7000 series Cabinets
When installing a server with processors running at speeds of 550 MHz or greater in Compaq Rack 7000

series racks with glass doors (165753-001 (42U), and 163747-001 (22U)), the new processor technology

requires the installation of Compaq’s High Airflow Rack Door Inserts (327281-B21 (42U), 327281-B22 (42U 6

pack), or 157847-B21 (22U)) to promote enhanced airflow for maximum cooling.

CAUTION: If a third-party rack is used, observe the following additional requirements to ensure adequate airflow

and to prevent damage to the equipment:

Front and rear doors: If your 42U server rack includes closing front and rear doors, you must allow

830 square inches (5,350 sq cm) of hole evenly distributed from top to bottom to permit adequate

airflow (equivalent to the required 64 percent open area for ventilation).

Side: The clearance between the installed rack component and the side panels of the rack must

be a minimum of 2.75 inches (7 cm).

CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This

arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling

that can lead to thermal damage.

Note: For additional information, refer to the Setup and Installation Guide or the Documentation CD provided with

the

server, or to the server documentation located in the Support section at the following URL:

http://www5.compaq.com/products/servers/ProLiantml570/index.html

.

Rack Kit

ML570 G2 rack models provide tool-free support for square hole racks (including Compaq/HP 7000, 9000, 10000

and H9 series) with an adjustment range from 28” – 29” in depth

Service and Support

Compaq Services provides a three-year, limited warranty, including Pre-Failure Warranty (coverage of hard drives,

memory and processors) fully supported by a worldwide network of resellers and service providers and lifetime toll-

free 7 x 24 hardware technical phone support. In addition, available service offerings include:

Note: Limited Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support.

A full range of CarePaq

packaged hardware and software services:

Installation and start up

Extended coverage hours and enhanced response times

System management and performance services

Availability and recovery services

Note: For more information, customer/resellers can contact

http://www.compaq.com/services

.

Please see the following URL regarding Warranty Information For Your Compaq Products:

http://www.compaq.com/support/warranty_upgrades/web_statements/176738.html

For additional information regarding Worldwide Limited Warranty and Technical Support, please see the following

URL:

ftp://ftp.compaq.com/pub/supportinformation/ejourney/176738.pdf

Note: Certain restrictions and exclusions apply. Consult the Compaq Customer Support Center at 1-800-345-1518

for details.
